Mark 7 Evolution User Manual page 4

Packaging Contents
TM
The Evolution press is packaged in a single corrugated box (26" X 21" X 16"). The main unit is heavy (60+
lbs.) Please use caution when handling and removing the Main Unit from the packaging.
2
1
38
39
6
Item No. Description
1 Case Feeder with Caliber Plate
2 Case Feeder Ramp
3 Case Feeder Spring Flipper Assy
4 Case Feeder Output Spring Assy
5 Case Drop Tube
6 1/4"-20 x 1/2" Screw
7 1/4" Screw Washer
8 Case Feed Pole Lower
9 Case Feeder Pole Connector
10 Case Feed Pole Upper
11 Case Feed Adapter
12 Evolution Main Unit
13 1/4" -20 x 3/16" Set Screw
14 Handle
15 Low Primer Alarm Sensor
16 Primer Backup Rod
17 Primer Tube Stack Assy
18 10-32 x 1/2" Flat Head Screw
19 Mechanical Powder Measure
20 Shaft Handle Adapter
4
Mark 7® Reloading EVOLUTION User Manual version 2.0, Copyright 2020
All rights reserved
3
10
6 7 8
0
4
5 9
31
36
32
30
37
33
34
35
QTY
1
1
1
1
1
8
8
1
1
1
1
1
2
1
1
1
1
3
1
1
12
11
0 0
27
28
29
Item No. Description
21 Main Shaft Crank Key
22 3/8"-16 x 4 1/2" Socket Cap Screw
23 Base Plate Feet
24 3/8" Screw Washer
25 3/8" Screw Lock Washer
26 3/8"-16 Nut
27 Spacer 1 1/4" Long
28 Spacer 5/8" Long
29 5/16" Screw Washer
30 5/16"-24 x 3/4" Screw
31 Case Feeder Pole Mounting Bracket
32 3/8"-16 x 2 3/4" Screw
33 3/8/"-16 x 2" Screw
34 Zip Tie
35 Cable Tie Holder
36 Case Retention Spring
37 Shell Plate Retention Spring
38 1/2" Allen Key
39 AkOffload Bin
14
0
13
0
20
18
21
0
22
23
24
19
25
0
26
QTY
15
0
17
0
16
0
1
4
4
4
4
4
1
1
4
4
2
1
1
4
4
2
2
1
1
