- Page 1 101-1196: Mark 7® Power Trim Xpress Instruction Manual V 1.1 Read this manual. Understand all safety and operating instructions. Failure to comply with the warnings and instructions may result in serious injury, illness or death. DIGITAL POWDER MEASURE INSTRUCTION MANUAL VERSION 1.1...
-
Page 2: Package Contents
Package Contents Item No. Description Brushless Trimmer Body Trim Die Adapter Socket Head Cap Screw, M5x0.8mm Thread, 10mm Long Vacuum Manifold 3/8” Carbide End Mill Trimmer Control Box Power Cord Digital Powder Measure Instruction Manual Version 1.1... -
Page 3: Setup And Operation
Set-up & Operation 1) Install the trim die in your press. Note: for some short cases such as the 300 AAC, the trim die lock ring may need to be installed on the underside of the die station rather than on top. An offset toolhead may also be required. - Page 4 3) We recommend that cases be sized before running them through the trim die. While the trim die is dimensioned to the same specs as a sizing die, sizing first will allow cases to run through the trim die smoother which promotes more uniform results. 4) Lube a case and cycle it through the trim die.
- Page 5 6) Connect the power cord from the trimmer to the control box and plug in the power cord from the control box to an outlet. 7) Move the power switch to On and set the motor speed to position 7-8. 8) Run a lubed case through the trim die and then check the overall length of the trimmed case.
-
Page 6: Troubleshooting
10) Lube your cases and begin trimming. The control box allows for varying the speed of the trimmer. Most often you will want to run it at a medium to high speed. Use the highest speed that produces a clean cut. If you see chatter, try slowing down the motor. Cartridge Conversion The trimmer can convert 223 cases into 300 AAC Blackout in one pass.
