Multitek MultiLed M812-LD Series Operating Manual page 58

4X REGS
Reg Modbus Reg Start Read (code 3)
Name Addr.
(dec)
Sys. V 40001
Sys. I 40003
Sys. Type 40005
Sys. Power 40007
Demand 40009
time
Demand 40011
period
Relay 40013
divisor
Relay 40015
pulse
width
Addr.
(hex)
0000 Get the system
voltage
0002 Get the system
current
0004 Get the sys. type
1= Single phase
2= 3 ph 3 wire
3= 3 ph 4 wire
0006 Get the sys power Illegal operation
0008 Get the demand
time (3-30min.)
000A Get the No. of sub Illegal operation
-intervals left to
integrate in the
1st demd. period
000C Get relay divisor
1, 10 or 100
000E Get the No. of
20ms in the relay ms in the relay
pulse width 0 to
10= off to 200ms 10 = off to200ms
57
Write (code 16)
Set the system
voltage
Set the system
current
Set the sys. type
1 = Single phase
2 = 3ph 3 wire
3 = 3 ph 4 wire
Set the demand
time (3-30min.)
Set relay divisor
1, 10 or 100
Set the No. of 20
pulse width 0 to
