Multitek MultiLed M812-LD Series Operating Manual page 14

3.4.4 Quadrant / Power Diagram
270°
Note the E in the above diagram signifies that the Export LED
annunciator is illuminated
3.4.5 Examples of Import and Export Power.
360°
0°
P.F.
P.F. = E
IMPORT
180°
VArs
3.4.5.1 Power factor at 0.5 lead (60deg).
Line 1 = Importing kW
Line 2 = Exporting kVAr
Line 3 = VA measurement.
13
IMPORT WATTS
P.F. = -
90°
EXPORT WATTS
P.F. = E-
EXPORT
VArs
