Page 18
4.3 LCD Support
S1D13506
X25B-G-014-02
The S1D13506 supports 4/8-bit dual and single passive monochrome panels, 4/8/16-bit
dual and single passive color panels, and 9/12/18-bit active matrix color TFT/D-TFD
panels. All necessary signals are provided on the 40-pin LCD connector (J1). The interface
signals are alternated with grounds on the cable to reduce cross-talk and noise. When
supporting an 18-bit TFT/D-TFD panel, the S1D13505 can display 64K of a possible 256K
colors because only 16 of the18 bits of LCD data are available from the S1D13505. For
details, refer to the S1D13506 Hardware Functional Specification, document number
X25B-A-001-xx.
For S1D13506 FPDAT[15:0] pin mapping for various types of panel see Table 4-7:, "LCD
Signal Connector (J4)" on page 19.
Epson Research and Development
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual
Issue Date: 2009/03/02
