The pinouts for Connector H2 are listed in the following table.
Table 4-6: CPU/BUS Connector (H2) Pinout
Pin No.
1 Connected to AB0 of the S1D13506
2 Connected to AB1 of the S1D13506
3 Connected to AB2 of the S1D13506
4 Connected to AB3 of the S1D13506
5 Connected to AB4 of the S1D13506
6 Connected to AB5 of the S1D13506
7 Connected to AB6 of the S1D13506
8 Connected to AB7 of the S1D13506
9 Ground
10 Ground
11 Connected to AB8 of the S1D13506
12 Connected to AB9 of the S1D13506
13 Connected to AB10 of the S1D13506
14 Connected to AB11 of the S1D13506
15 Connected to AB12 of the S1D13506
16 Connected to AB13 of the S1D13506
17 Ground
18 Ground
19 Connected to AB14 of the S1D13506
20 Connected to AB15 of the S1D13506
21 Connected to AB16 of the S1D13506
22 Connected to AB17 of the S1D13506
23 Connected to AB18 of the S1D13506
24 Connected to AB19 of the S1D13506
25 Ground
26 Ground
27 +5 volt supply, required in non-PCI applications
28 +5 volt supply, required in non-PCI applications
29 Connected to RD/WR# of the S1D13506
30 Connected to BS# of the S1D13506
31 Connected to S1D13506 BUSCLK if JP1 is in position 2-3
32 Connected to RD# of the S1D13506
33 Connected to AB20 of the S1D13506
34 Not connected
Function
