Testing the USB-UART Driver Installation
9.
10. Set the SACE MODE DIP switches as shown in
11. Press the SYS ACE RESET button (SW9) shown in
X-Ref Target - Figure 25
12. After a lapse of 5 to 10 seconds, you should see the output shown in
SP605 Getting Started Guide
UG727 (v1.1) June 21, 2010
Start a serial communication program like HyperTerminal or TeraTerm on the Host PC
with the following settings:
•
Baud Rate: 9600
•
Data Bits: 8
•
Parity:
None
•
Stop Bits: 1
•
Flow Control: None
Demo. Make sure the Compact FLASH card is still inserted.
Figure 25: SP605 SYSACE RESET Button
serial communication window.
www.xilinx.com
Installation and Licensing of ISE Design Suite 12.1
Figure 3
and listed in
Figure 25
UG727_27_051110
Table
2.
to re-load the Video
Figure 26
on your
29
