10
BIOS Setup Description
The BIOS setup description of the conga-TCA7 can be viewed without having access to the module. However, access to the restricted area of
the congatec website is required in order to download the necessary tool (CgMlfViewer) and Menu Layout File (MLF).
The MLF contains the BIOS setup description of a particular BIOS revision. The MLF can be viewed with the CgMlfViewer tool. This tool offers
a search function to quickly check for supported BIOS features. It also shows where each feature can be found in the BIOS setup menu.
For more information, read the application note "AN42 - BIOS Setup Description" available at www.congatec.com.
Note
If you do not have access to the restricted area of the congatec website, contact your local congatec sales representative.
10.1
Navigating the BIOS Setup Menu
The BIOS setup menu shows the features and options supported in the congatec BIOS. To access and navigate the BIOS setup menu, press the
<DEL> or <F2> key during POST. The right frame displays the key legend. Above the key legend is an area reserved for text messages. These
text messages explain the options and the possible impacts when changing the selected option in the left frame.
10.2
BIOS Versions
The BIOS displays the BIOS project name and the revision code during POST, and on the main setup screen. The initial production BIOS for
conga-TCA7 is identified as TA70R0xx, where:
• R is the identifier for a BIOS ROM file
• 0 is the so called feature number
• xx is the major and minor revision number
The TA70 binary size is 32 MB.
Copyright © 2021 congatec GmbH
TA70m01
66/67
