Table 27 LPC Signal Descriptions
Signal Pin Description
LPC_AD[0:3] B4-B7 LPC Mode: LPC multiplexed address, command and data bus
LPC_FRAME# B3 LPC Mode: LPC Frame indicates the start of a LPC cycle.
LPC_CLK B10 LPC Mode: LPC clock output, 33MHz
LPC_DRQ[0:1]# B8 LPC Mode: LPC serial DMA request
LPC_SERIRQ A50 LPC Mode: LPC serial interrupt
SUS_STAT# B18 LPC Mode: Indicates imminent suspend operation. It is used to notify LPC
devices that a low power state will be entered soon. LPC devices may need to preserve
memory or isolate outputs during the low power state.
ESPI_EN# B47 This signal is used by the carrier to indicate the operating mode of the LPC/eSPI bus. If left
1
unconnected on the carrier, LPC mode (default) is selected.
If pulled to GND on the carrier, eSPI mode is selected. This signal is pulled to a logic high on
the module through a resistor. The carrier should only float this line or pull it low.
Note
1. The conga-TCA7 does not support eSPI mode.
Table 28 SPI BIOS Flash Interface Signal Descriptions
Signal Pin Description
SPI_CS# B97 Chip select for Carrier Board SPI BIOS Flash
SPI_MISO A92 Data in to module from carrier board SPI BIOS flash
SPI_MOSI A95 Data out from module to carrier board SPI BIOS flash
1
SPI_CLK A94 Clock from module to carrier board SPI BIOS flash
SPI_POWER A91 Power source for carrier board SPI BIOS flash
SPI_POWER shall be used to power SPI BIOS flash on the carrier only
BIOS_DIS0# A34 Selection strap to determine the BIOS boot device
1
BIOS_DIS1# 1 B88 Selection strap to determine the BIOS boot device
Refer to table 4.13 of the COM Express Module Base Specification 3.0
for strapping options of BIOS disable signals
Note
1. Signal has special functionality during the reset process and may bootstrap some basic important functions of the module. For more
information refer to section 8.2 "Bootstrap Signals".
