Congatec COM Express conga-TCA7 User Manual page 24

Com express type 6 compact module based on the intel® atom™, pentium™ and celeron® elkhart lake soc

Table of Contents

For Lidded Variants

87 ±0.15

21.49 ±0.15

40.17 ±0.15

2.75±0.10

(Without thermal pad)

11±0.10

2.75±0.10

Without thermal pad

6±0.10 - 6X

NOTES:

M2.5 x 11 mm

threaded standoff

for threaded version

ø2.7 x 11 mm

non-threaded standoff

for borehole version

TA70m01

0.8

24/67
