Congatec COM Express conga-TCA7 User Manual page 45

Pin Row C
C33 DDI2_CTRLDATA_AUX-
C34 DDI2_DDC_AUX_SEL
C35 RSVD
1
C36 DDI3_CTRLCLK_AUX+ 1
C37 DDI3_CTRLDATA_AUX-
1
C38 DDI3_DDC_AUX_SEL 1
C39 DDI3_PAIR0+
1
C40 DDI3_PAIR0-
1
C41 GND (FIXED)
C42 DDI3_PAIR1+
1
C43 DDI3_PAIR1- 1
C44 DDI3_HPD
1
C45 RSVD
1
C46 DDI3_PAIR2+ 1
C47 DDI3_PAIR2-
1
C48 RSVD 1
C49 DDI3_PAIR3+
1
C50 DDI3_PAIR3-
1
C51 GND (FIXED)
C52 PEG_RX0+
1
C53 PEG_RX0- 1
C54 TYPE0#
1
C55 PEG_RX1+
1
Note
Not connected
1.
Not supported
2.
Copyright © 2021 congatec GmbH
Pin Row D Pin
D33 DDI1_PAIR2- C88
D34 DDI1_DDC_AUX_SEL C89
D35 RSVD C90
1
D36 DDI1_PAIR3+ C91
D37 DDI1_PAIR3- C92
D38 RSVD 1 C93
D39 DDI2_PAIR0+ C94
D40 DDI2_PAIR0- C95
D41 GND (FIXED) C96
D42 DDI2_PAIR1+ C97
D43 DDI2_PAIR1- C98
D44 DDI2_HPD C99
D45 RSVD C100
1
D46 DDI2_PAIR2+ C101
D47 DDI2_PAIR2- C102
D48 RSVD 1 C103
D49 DDI2_PAIR3+ C104
D50 DDI2_PAIR3- C105
D51 GND (FIXED) C106
D52 PEG_TX0+ C107
1
D53 PEG_TX0- 1 C108
D54 PEG_LANE_RV# C109
1
D55 PEG_TX1+ C110
1
Row C Pin Row D
PEG_RX11+ 1 D88 PEG_TX11+
PEG_RX11- D89 PEG_TX11-
1
GND (FIXED) D90 GND (FIXED)
PEG_RX12+ 1 D91 PEG_TX12+
PEG_RX12- D92 PEG_TX12-
1
GND D93 GND
PEG_RX13+ D94 PEG_TX13+
1
PEG_RX13- D95 PEG_TX13-
1
GND D96 GND
RVSD D97 RSVD
1
PEG_RX14+ 1 D98 PEG_TX14+
PEG_RX14- D99 PEG_TX14-
1
GND (FIXED) D100 GND (FIXED)
PEG_RX15+ 1 D101 PEG_TX15+
PEG_RX15- D102 PEG_TX15-
1
GND D103 GND
VCC_12V D104 VCC_12V
VCC_12V D105 VCC_12V
VCC_12V D106 VCC_12V
VCC_12V D107 VCC_12V
VCC_12V D108 VCC_12V
VCC_12V D109 VCC_12V
GND (FIXED) D110 GND (FIXED)
TA70m01
1
1
1
1
1
1
1
1
1
1
1
45/67
