BVM PNP F-86 Construction And Operating Manual page 16

Control Surface Deflections and Expo Settings
Control
Elevator
(measured at the Root)
Aileron (measured at
the Ail/Flap Junction)
Rudder (measured at the
Bottom of the top
rudder)
Control
Flaps
Elevator Mix with flaps
Note: The BVM Demo plane is setup using the above Expo percentages. Positive values are
used on Spektrum and JR radios, Futaba uses negative.
Connecting RX wires
The wires are labeled from the factory. If you are using the DX18, the program is available on
a SD card from BVM. Follow the chart below to connect the servos.
DX18 Connection Chart
RX Port Throttle Aileron
Surface Throt R Ail
RX Port Aux4 Aux5
Surface L Elev
RX Port X+7 X+8
Surface Batt 2
PowerBox
Switch 2
Batts
BVM®2017
High Rate Expo
Up 20%
Up .75"
Down
Down .5"
20%
Up .80" 20% /
Down .80" 20%
Left 1.0" 20% /
Right 1.0" 20%
Take-Off Landing
Position Position
.70" 1.8"
.20" Up .25" Up
Elevator Rudder
R Elev Rudd
X+1 X+2
Gear
Medium
Expo
Rate
Up 15%
Up .5"
Down
Down .5"
15%
Up .60" 15% /
Down .60" 15%
Left .75" 15% /
Right .75" 15%
measured at the Ail/Flap Junction
measured at the Root
Gear Aux1
L Flap L Ail
X+3 X+4
Brake NG Steering
Mixed with
Rudder
15
Low
Expo
Rate
Up 10%
Down 10%
Up .50"
Down 10% / 10%
.50"
Left .5"
10% / 10%
Right .5"
Aux2 Aux3
R Flap Gyro
X+5 X+6
11/07/2017
