DEMO MANUAL DC1805A

parts List

ITEM QTY REFERENCE
1 14 C1, C2, C3, C4, C6, C7, C8, C10, C15,
C16, C18, C20, C21, C28
2 5 C22, C35, C38, C41, C44
3 1 C9
4 7 C5, C11, C17, C37, C40, C43, C46
5 1 C12
6 1 C19
7 1 C24
8 0 C13, C14, C23, C25, C30, C31, C32, C33 Capacitor, 0603
9 3 C26, C27, C29
10 1 C34
11 4 C36, C39, C42, C45
12 8 C47, C48, C49, C50, C51, C52, C53, C54 Capacitor, X7R, 0.1µF , 16V,10%, 0402
13 5 E1, E2, E3, E4, E5, E6, E7, E8, E9
14 3 J1, J2, J3
15 1 J4
16 1 J5
17 1 J6
18 5 JP1-JP5
19 1 R1
20 11 R2, R3, R13, R14, R15, R17, R20, R21,
R26, R27, R30
21 5 R4, R7, R8, R9, R44
22 4 R5, R10, R12, R23
23 0 R6, R11, R16, R24, R25
24 2 R18, R28
25 2 R19, R29
26 1 R22
27 3 R31, R32, R33
28 1 R34
29 4 R36, R37, R38, R40
30 1 R39
31 1 R41
32 1 R42
33 1 R43
34 2 U1, U6
35 2 U2, U5
36 1 U3
37 1 U4
38 1 U7
39 1 U9
40 1 U10
6
PART DESCRIPTION
Capacitor, X7R, 0.1µF , 25V, 10%, 0603
Capacitor, X7R, 1µF , 16V, 10%, 0603
Capacitor, X5R, 47µF 6.3V, 20%, 0805
Capacitor, X5R, 10µF 6.3V, 20%, 0603
Capacitor, X7R, 4.7µF 10V, 10%, 0805
Capacitor, X7R, 0.1µF , 25V, 5%, 0805
Capacitor, X7R, 0.01µF , 16V,10%, 0402
Capacitor, Ceramic 3900pF , 100V NPO,1206
Capacitor, X5R, 22µF 16V, 20%, 1210
Capacitor, X7R, 0.01µF , 16V,10%,0603
TP , Turret, 0.094"
Connector, BNC-5PINS
Connector, 40 Pins SMT, CON-EDGE40-100
Header, 2×7, 0.079"
Header, 2×5, 0.100", HD2X5-100
Jumper, 1×3, 0.100", HD1X3-100
Resistor, Chip 49.9, 1%, 1206
Resistor, Chip 1k, 1%, 0603
Resistor, Chip 33, 1%, 0603
Resistor, Chip 0, 1%, 0603
Resistor, 0603
Resistor, Chip 35.7, 1%, 0603
Resistor, Chip 0, 1/16W, 1%, 0402
Resistor, Chip 2k, 1%, 0603
Resistor, Chip 4.99k, 1%, 0603
Resistor, Chip 10k, 1%, 0402
Resistor, Chip 1k, 1%, 0402
Resistor, Chip 10k, 1%, 0603
Resistor, Chip 2.80k, 1%, 0603
Resistor, Chip 1.69k, 1%, 0603
Resistor, Chip 1.54k, 1%, 0603
IC., Tinylogic UHS Inverter, SC70-5
IC., Tinylogic ULP-A Unbuffered Inverter, SC70-5
IC., LTC6655CHMS8-5, MS8
IC., Single D Flip Flop, US8
IC., Single SPST Bus Switch, SC70-5
IC., LTC6362CMS8, MS8
IC., Serial EEPROM, TSSOP
MANUFACTURER/PART NUMBER
AVX, 06033C104KAT2A
AVX, 0603YC105KAT2A
Taiyo Yuden, JMK212BJ476MG-T
TDK, C1608X5R0J106MT
AVX, 0805ZC475KAT2A
AVX, 08053C104JAT2A
AVX, 0402YC103KAT2A
OPT
AVX, 12061A392JAT2A
Taiyo Yuden, EMK325BJ226MM-T
AVX, 0603YC103KAT
TDK, C1005X7R1C104KT
Mill-Max, 2501-2-00-80-00-00-07-0
Connex, 112404
Samtec, TSW-120-07-L-D
Molex, 87831-1420
Samtec, TSW-105-07-L-D
Samtec, TSW-103-07-L-S
NIC, NRC12F49R9TRF
NIC, NRC06F1001TRF
NIC, NRC06F33R0TRF
NIC, NRC06F0000TRF
OPT
Vishay, CRCW060335R7FKEA
NIC, C04F0000TRF
NIC, NRC06F2001TRF
NIC, NRC06F4991TRF
NIC, NRC04F1002TRF
NIC, NRC04F1001TRF
NIC, NRC06F1002TRF
NIC, NRC06F2801TRF
NIC, NRC06F1691TRF
NIC, NRC06F1541TRF
Fairchild, NC7SZ04P5X
Fairchild, NC7SVU04P5X
Linear Technology, LTC6655CHMS8-5#PBF
ON Semiconductor, NL17SZ74 (USG)
Fairchild, NC7SZ66P5X
Linear Technology, LTC6362CMS8
Microchip, 24LC024-I/ST
