DEMO MANUAL DC1007C

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C3
4 1 C6
5 1 L1
6 1 R5
7 2 R6, R7
8 1 R14
9 1 U1
Additional Demo Board Circuit Components
10 1 C4
11 1 C5
12 1 C7
13 1 D1
14 1 Q1
15 2 R1, R2
16 4 R3, R4, R8, R9
17 1 R10
18 0 R11 (OPT)
19 0 R12 (OPT)
20 1 R13
Hardware: For Demo Board Only
21 1 J1
22 6 E1, E2, E8, E9, E10, E11
23 10 E3, E4, E5, E6, E7, E12, E13, E14,
E15, E16
24 4 JP1, JP2, JP3, JP4
25 4
6
PART DESCRIPTION
CAP , CHIP , X5R, 1.0µF, 6.3V, 0402
CAP , CHIP , X5R, 10µF, 10V, 0805
CAP , CHIP , X5R, 22µF, 6.3V, 0805
CAP , CHIP , X7R, 0.1µF, 16V, 0402
IND, 3.3µH, 0.08Ω, 2.2A
RES, 0402 2.94k 1% 1/16W
RES, 0402 2k 1% 1/16W
RES, 0402 8R 25Ω 1% 1/16W
IC, USB BAT CHARGER/POWER MANAGER, DFN-14
CAP , CHIP , X5R, 22µF, 6.3V, 0805
CAP , CHIP OS-CON, 100µF, 6.3V, B6
CAP , CHIP , X5R, 10µF, 10V, 0805
LED 565NM GRN DIFF 0603 SMD
XSTR, MOSFET P-CHANNEL
RES, 0402, 100k, 1%, 1/16W
RES, 0402 0R 0Ω 1/16W
RES, 0402 510Ω 1% 1/10W
RES., OPTION, 0402
RES, 0402 0R 0Ω 1/16W
RES., 1Ω, 1%, 1/16W, 0402
CONN, USB MINI-B
TEST POINT, TURRET, 0.094", MTG. HOLE
TEST POINT, TURRET, 0.064", MTG. HOLE
HEADER, 3 PINS 2mm
STANDOFFS
MANUFACTURER/PART NUMBER
MURATA, GRM155R60J105ME19D
MURATA, GRM21BR61A106KE19L
MURATA, GRM21BR60J226ME39L
MURATA, GRM155R71C104KA88D
COILCRAFT, LPS4018-332MRC
VISHAY, CRCW04022K94FKED
VISHAY, CRCW04022K00FKED
VISHAY, CRCW04028R25FNED
LTC4088EDE
MURATA, GRM155R60J105ME19D
PANASONIC, 6SVPC100MY
MURATA, GRM21BR61A106KE19L
LUMEX OPTO/COMPONENTS INC,
SML-LX0603GW-TR
SILICONIX, Si2333DDS
VISHAY, CRCW0402100KFKED
VISHAY CRCW04020000Z0ED
VISHAY CRCW0402 5100 1%
OPT
VISHAY CRCW04020000Z0ED
VISHAY, CRCW04021R00FKED
TYCO 440247-1
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
COMM 2802S-03G2
KEYSTONE, 8831
