Parts List - Linear Technology DC2339A Demo Manual

DEMO MANUAL DC2339A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 6 C1, C2, C24, C25, C30, C31
2 2 C4, C5
3 1 C6
4 1 C7
5 1 C8
6 1 C9
7 3 C11, C12, C16
8 1 C14
9 4 C18, C21, C22, C23
10 5 C26-C29, C19
11 1 D1
12 2 D3, D4
13 1 L1
14 2 Q1, Q2
15 2 Q3, Q5
16 3 Q4, Q6, Q7
17 3 Q8-Q10
18 6 R1, R4, R12, R13, R33, R36
19 10 R3, R6-R8, R10, R20-R23, R25
20 2 R5, R32
21 1 R14
22 1 R16
23 3 R17, R18, R19
24 1 R27
25 3 R29, R30, R31
26 1 U1
Additional Demo Board Circuit Components
1 0 C10, C13, C15(OPT)
2 0 C17 (OPT)
3 0 D2(OPT)
4 0 R2, R9(OPT)
Hardware: For Demo Board Only
1 16 E1-E16
2 8 J1-J8
3 4 STAND-OFF
4
PART DESCRIPTION
CAP., X7R, 10µF, 50V, 10%, 1210
CAP., ALUM., ELECT., 56µF, 50V
CAP., X7R, 0.22µF, 25V, 10% 0603
CAP., X7R, 1µF, 50V, 10% 0805
CAP., X7R, 22µF, 6.3V, 10% 0805
CAP., X5R, 47µF, 10V, 10% 1206
CAP., POSCAP, 470µF, 6.3V, D4D
CAP., X5R, 2.2µF, 25V, 10% 0603
CAP., X7R, 10nF, 25V, 10% 0603
CAP., X7R, 1nF, 25V, 10% 0603
SCHOTTKY RECTIFIER, 40V, SOD523
DIODE, BAT54A SOT23
INDUCTOR, 0.82µH
N-CH., 40-V, PG-TDSON-8
N-CH., 40-V, PG-TDSON-8
N-CH., 12-V, PowerPAK SO-8
N-CH., 40-V, PG-TDSON-8 FL
RES., CHIP., 0Ω, 1/10W, 0603
RES., CHIP., 100K, 1/10W, 1% 0603
RES., CHIP., 0.003Ω, 3W, 1%, KRL6432
RES., CHIP., 4.02K, 1/10W, 1% 0603
RES., CHIP., 82.5K, 1/10W, 1% 0603
RES., CHIP., 309K, 1/10W, 1% 0603
RES., CHIP., 1k, 1/10W, 1% 0603
RES., CHIP., 25.5k, 1/10W, 1% 0603
I.C. LT3744EUHE 36PIN, UHE
CAP., D4D
CAP., 0603
DIODE, DI123
RES., CHIP., 0603
TESTPOINT, TURRET, 0.094"
JACK BANANA
STAND-OFF, NYLON, 0.25" (SNAP ON)
MANUFACTURER/PART NUMBER
MURATA, GRM32ER71H106KA12L
SUN ELECT., 50HVT56M
MURATA, GRM188R71E224KA88D
AVX, 08055C105KAT2A
AVX, 08056D226KAT2A
MURATA, GRM31CR61A476KE15L
PANASONIC, 6TPF470MAH
MURATA, GRM188R61E225KA12D
AVX, 06033C103KAT2A
AVX, 06033C102KAT2A
NXP, PMEG4002EB
DIODES INC., BAT54A-7-F
Würth Elektronik, 744355182
INFINEON, BSC035N04LS G
INFINEON, BSC026N04LS
VISHAY, Si7234DP-T1-GE3
INFINEON, BSC010N04LS
VISHAY, CRC06030000Z0EA
VISHAY, CRCW0603100KFKEA
SUSUMU, KRL6432E-M-R003-F
VISHAY, CRCW06034K02FKEA
VISHAY, CRCW060382K5FKEA
VISHAY, CRCW0603309KFKEA
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW060325K5FKEA
LINEAR TECH., LT3744EUHE#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8831
dc2339af
