Parts List; Part Description - Linear Technology DC2455A-C Demo Manual

parts List

ITEM QTY
Required Circuit Components
1 1
2 2
3 8
4 8
5 16
6 16
7 1
8 4
9 7
10 1
11 1
12 1
13 1
14 2
15 8
16 1
17 1
18 1
19 1
20 2
21 4
22 9
23 4
24 1
25 1
26 1
27 1
28 1
29 1
30 1
31 1
32 1
33 3
34 1
35 1
36 1
37 2
38 1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE
CIN1
CIN2, CIN11
CIN3-CIN10
CIN12-CIN19
CO1, CO2, CO5, CO6, CO7, CO8, CO11,
CO13, CO15, CO16, CO24, CO55, CO56,
CO57, CO58, CO59
CO20, CO21, CO22, CO26, CO27, CO28,
CO30, CO32, CO33, CO34, CO35, CO36,
CO48, CO50, CO52, CO54
C1
C4, C10, C18, C22
C6, C11, C19, C23, COUT26, C42, C43
C7
C31
C39
C40
C41, C48
C41, C44, C45, C48, C52, C53, C54, C55
C46
C47
C49
L1
Q1, Q2
R1, R3, R25, R29
R2, R9, R14, R21, R31, R39, R43, R47, R51 RES, 0603 121kΩ 1% 1/10W
R4, R36, R41, R98
R11
R15
R16
R17
R18
R89
R92
R93
R94
R95, R96, R107
R97
R99
R100
R101, R102
R103
DEMO MANUAL DC2455A-C

PART DESCRIPTION

CAP , 150µF 25% 25V ALUM
CAP , 1206 1µF 10% 25V X5R
CAP , 1210 22µF 10% 25V X5R
CAP , 1210 22µF 10% 25V X5R
CAP , 1206 220µF 20% 4V X5R
CAP , 1206 220µF 20% 4V X5R
CAP , 0603 330pF 10% 50V X7R
CAP , 0603 4.7µF 20% 10V X5R
CAP , 0603 1µF 10% 10V X7R
CAP , 0603 0.1µF 10% 25V X7R
CAP , 0603 15nF 10% 50V X7R
CAP , 0603 100nF 10% 100V X7R
CAP , 0603 150pF 5% 50V C0G
CAP , 1210 100µF 10V X5R
CAP , 1210 100µF 10% 6.3V X5R
CAP , 1210 10µF 16V X5R
CAP , 0603 220pF 10% 50V X7R
CAP , 0603 47nF 10% 50V X7R
IND, 68µH, CDRH105
MOSFET, N-CH D-S 40V TO252
RES, 0603 10Ω 5% 1/10W
RES, 0603 10kΩ 5% 1/10W
RES, 0603 1.74kΩ 1% 1/10W
RES, 0603 90.9kΩ 1% 1/10W
RES, 0603 60.4kΩ 1% 1/10W
RES, 0603 40.2kΩ 1% 1/10W
RES, 0603 30.1kΩ 1% 1/10W
RES, 0603 2Ω 1% 1/10W
RES, 0603 3.3Ω 1% 1/10W
RES, 0603 154kΩ 1% 1/10W
RES, 0603 1MΩ 5% 1/10W
RES, 0603 20kΩ 5% 1/10W
RES, 0603 681kΩ 1% 1/10W
RES, 0603 301Ω 1% 1/10W
RES, 0603 82.5Ω 1% 1/10W
RES, 2512 0.010Ω 1% 1W
RES POT, 5k
MANUFACTURER/PART NUMBER
SUN ELECT., 25HVH150M
TAIYO YUDEN, TMK316BJ105KD-T
AVX, 12103D226KAT2A
AVX, 12103D226KAT2A
MURATA, GRM31CR60G227ME11L
MURATA, GRM31CR60G227ME11L
AVX, 06035C331KAT2A-CT
TAIYO YUDEN, LMK107BJ475MA-T
TAIYO YUDEN, LMK107BJ105KA-T
AVX, 06033C104KAT2A
AVX, 06035C153KAZ2A
MURATA, GRM188R72A104KA35D
AVX, 06035A151JAT2A
MURATA, GRM32ER61A107ME20L
MURATA, GRM32ER60J107ME20L
MURATA, GRM32DR61C106KA01L
AVX, 06035C221KAT2A
AVX, 06035C473KAZ2A
SUMIDA CDRH105RNP-680N
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW0603121KFKEA
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW06031K74FKEA
VISHAY, CRCW060390K9FKEA
VISHAY, CRCW060360K4FKEA
VISHAY, CRCW060340K2FKEA
VISHAY, CRCW060330K1FKEA
VISHAY CRCW06032R00FNEA
VISHAY, CRCW06033R3FKEA
VISHAY, CRCW0603154KFKEA
VISHAY CRCW06031M00JNEA
VISHAY, CRCW060320K0JNTA
VISHAY, CRCW0603681KFKEA
VISHAY, CRCW0603301RFKEA
VISHAY, CRCW060382R5FKEA
VISHAY, WSL2512R01000FEA
BOURNS 3386P-1-502-LF
dc2455acf
5
