Linear Technology DC1805A Series Manual page 7

parts List
ITEM QTY REFERENCE
41 1 U11
42 1 U12
43 1 U13
44 1 U14
45 1 U15
46 4 MH1-MH4
47 5 Shunts as Shown on Assembly Drawing
(JP1-JP5)
48 2 Stencil for Top and Bottom
DC1805A-A
1 1 DC1805A-A
2 1 U8
3 0 R35 (OPT)
DC1805A-B
1 1 DC1805A-B
2 1 U8
3 0 R35 (OPT)
DC1805A-C
1 1 DC1805A-C
2 1 U8
3 0 R35 (OPT)
DC1805A-D
1 1 DC1805A-D
2 1 U8
3 0 R35 (OPT)
DC1805A-E
1 1 DC1805A-E
2 1 U8
3 1 R35
DC1805A-F
1 1 DC1805A-F
2 1 U8
3 1 R35
DC1805A-G
1 1 DC1805A-G
2 1 U8
3 1 R35
DC1805A-H
1 1 DC1805A-H
2 1 U8
3 1 R35
DEMO MANUAL DC1805A
PART DESCRIPTION
IC., LT1763CS8-1.8, SO8
IC., LT1763CS8, SO8
IC., MAX II Family, TQFP100
IC., LT1763CS8-2.5, SO8
IC., LT1763CS8-5, SO8
Stand-Off, Nylon (Snap On), 0.375" Tall
Shunt, .100" Center
General BOM
IC., LTC2380CMS-16, MS16
Resistor, Chip 300Ω, 1%, 0402
General BOM
IC., LTC2378CMS-16, MS16
Resistor, Chip 300Ω, 1%, 0402
General BOM
IC., LTC2377CMS-16, MS16
Resistor, Chip 300Ω, 1%, 0402
General BOM
IC., LTC2376CMS-16, MS16
Resistor, Chip 300Ω, 1%, 0402
General BOM
IC., LTC2379CMS-18, MS16
Resistor, Chip 300Ω, 1%, 0402
General BOM
IC., LTC2378CMS-18, MS16
Resistor, Chip 300Ω, 1%, 0402
General BOM
IC., LTC2377CMS-18, MS16
Resistor, Chip 300Ω, 1%, 0402
General BOM
IC., LTC2376CMS-18, MS16
Resistor, Chip 300Ω, 1%, 0402
MANUFACTURER/PART NUMBER
Linear Technology, LT1763CS8-1.8#PBF
Linear Technology, LT1763CS8#PBF
Altera, EPM240GT100C5N
Linear Technology, LT1763CS8-2.5#PBF
Linear Technology, LT1763CS8-5#PBF
Keystone, 8832 (Snap On)
Samtec, SNT-100-BK-G
Stencil #DC1805A-2
Linear Technology, LTC2380CMS-16
OPT
Linear Technology, LTC2378CMS-16
OPT
Linear Technology, LTC2377CMS-16
OPT
Linear Technology, LTC2376CMS-16
OPT
Linear Technology, LTC2379CMS-18
NIC, NRC04F3000TRF
Linear Technology, LTC2378CMS-18
NIC, NRC04F3000TRF
Linear Technology, LTC2377CMS-18
NIC, NRC04F3000TRF
Linear Technology, LTC2376CMS-18
NIC, NRC04F3000TRF
dc1805af
7
