DEMO MANUAL DC2120A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C4
4 1 C3
5 1 L1
6 1 U1
7 1
Additional Demo Board Circuit Components
1 1 C5
Hardware: For Demo Board Only
1 4 E1-E4
2 1 JP1
3 1 XJP1
4 1
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP., X7R, 4.7µF, 25V, 10%, 0805
CAP., X7R, 2.2µF, 25V, 10%, 0805
CAP., X7R, 1µF, 25V, 10%, 0603
CAP., C0G, 1nF, 25V, 5%, 0603
INDUCTOR, 10µH
IC., LT3048EDC-15#PBF, DFN-2X2, 8 LEAD
FAB, PRINTED CIRCUIT BOARD
CAP., X7R, 1µF, 25V, 10%, 0603
TESTPOINT, TURRET, 0.094"
3 PIN 0.079" SINGLE ROW HEADER
SHUNT, 0.079" CENTER
STENCIL
MANUFACTURER/PART NUMBER
TDK, C2012X7R1E475K
TDK, C2012X7R1E225K
TDK, C1608X7R1E105K
MURATA GRM1885C1E102JA01D
COOPER Bussmann, SD3110-100-R
LINEAR TECH., LT3048EDC-15#PBF
DEMO BOARD 2120A
TDK, C1608X7R1E105K
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN031PAEN-RC
SAMTEC, 2SN-BK-G
STENCIL DC2120A
dc2120af
