SPECIFICATIONS
Process and Memory
Connectors
LED and Button
Antenna
Power Adapter
Compliance
Dimensions (H x W x D)
Weight
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Part
JOHNSON CONTROLS CONFIDENTIAL AND PROPRIETARY
SSoC: MT7621DA (MIPS1004Kc dual-core 880MHz, SPI NOR Flash 64MB)
Memory: 128MB DDR3 embedded
1 DC Power Jack
2 RJ-45 Connectors
LEDs: 4 Single Color LED
Buttons:
1 WPS Button on the side
1 Reset button on the back
4 Wi-Fi internal antennas
Input: 100-240VAC, 50-60Hz, 0.3A Max
Output: 12 VDC, 1A
FCC
150mm x 89mm x 57.2mm
172g
0°C - 40°C (32°F - 104°F)
10% - 90% RH (non-condensing)
-20°C -60°C (-4°F - 140°F)
5% - 95% RH (non-condensing)
PAGE
43
OF
45
