CONTROLLER AND AGENTS DO NOT SYNC
If you are experiencing difficulty syncing the controller and the agent, we
recommend that you move the agent into the same room as the
controller during the sync. Then move the agent to a different location.
To sync the controller and the agent (see page 14):
1. Place the agent in the same room as the IQ WIFI. Use this agent
location only during the sync process.
2. Connect the agent to a power source.
3. Wait for the agent power LED to light solid GREEN.
4. Press the WPS button on the controller and then within two minutes,
press the WPS button on the agent.
5. Wait for the agent internet LED to light solid GREEN. The agent
WiFi LED will slowly blink GREEN when communicating.
6. Move the agent to a new location and connect the agent to a power
source.
7. At the new location, check the agent power LED and make sure it is
solid GREEN.
If the agent error LED lights up RED, make sure you are within range
and try again.
JOHNSON CONTROLS CONFIDENTIAL AND PROPRIETARY
PAGE 38 OF 45
Agent
Controller
