CONNECTING ADDITIONAL AGENTS
You may choose to improve the WIFI network by adding additional "agents" to the network (up to 7). Agents
must be within range of IQ WIFI in order to sync wirelessly.
1
Example of where controllers and agents
may be placed for best performance.
Choose your location to maximize your
mesh WI-FI network. Ensure desired
location has an available power outlet.
2
Connect both ends of the power supply to
an available outlet.*
*You may choose to connect your agents
power close to your controller during the
pairing process and move to your desired
location once pairing is complete.
JOHNSON CONTROLS CONFIDENTIAL AND PROPRIETARY
PAGE
Once the agent has powered up
completely, the power LED will stop
flashing. Activate WPS on the controller,
then activate WPS on the agent
13
OF
45
3
Controller
Agent
