INSTALLATION
1.
Cut the tape of one of wheel support assembly box as
shown in fig.-1.
2.
Remove the 4 no's of Foam sheets as shown in fig.-2.
3.
Uplift the Wheel Support assembly as shown in fig.-3.
4.
Place the wheel support genteelly on the floor as shown
in fig.-4.
5.
Uplift the top cover as shown in fig.-5 & place it close to
the wheel support assembly & Kindly repeat the same
procedure for other wheel support assembly as well.
6.
Place both the wheel support assemblies on the floor
close to each other & take out 2 No's. each of screws
already mounted on both the wheel support assemblies
Receptively with the provided Allen wrench (8mm) as
shown in fig.-6.
6135000-795
PRIMA OPH
Prima OPH
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Fig 6
14
Issue 1.6
Printed on: July, 2020
