AT2511/511C User's Guide
12

3.4 Select Test Speed

2 test speed is available for the instrument:
Slow ： 3 t/s
Fast ： 10 t/s
Press Speed key ， switch speed, correspond indicator indicates current speed.

3.5 Select Range

Under status of AUTO range, the AUTO indicator is lit, and the range indicator indicates the current
range.
AT2511 will choose the fit range to measure according to the following table:
SENSE+
DRIVE+
To make sure instrument's accuracy, please use the "Kalvin Test Clip" that follows the
instrument to test.
No putting current source, voltage source directly access test side. Energy storage device
access to testing after discharging.
SENSE-
DRIVE-
