Dimensional drawings
What this chapter contains
This chapter contains the dimensional drawings of the fastening points in the drive
modules used in the installation examples in this manual. Dimensional drawings of
air baffles and EMC screens are also shown. The dimensions are given in
millimetres. 1 mm = 0.03936996 in..
For other dimensional drawings, refer to ACS800-04/04M/U4 Cabinet Installation
[3AFE68360323 (English)].
43
Dimensional drawings
