Roborock S5 Max User Manual page 12

Installation
Using the robot
Attach the mop cloth bracket
�
Slide the mop cloth bracket under the water tank following
the alignment marks, until you hear a click.
Note:
Cleaning the mop cloth after ��-minutes of mopping is recommended to
ensure water flow and cleaning quality.
�. Adjust water flow rate
Use the mobile app to adjust the water flow as required.
Low WaterLevel Medium Water Level
�. Start cleaning
When the battery is fully charged, the power indicator will
remain lit. Press the button or use the app to start cleanup.
High Water Level
�. Remove the mop cloth bracket
To remove the mop cloth bracket, press the two clips
inwards and pull the bracket backwards.
Note:
· When the charging dock is placed on a wooden floor, always use it with the
moisture-proof mat to prevent moisture damage.
· Removing and washing the mop cloth bracket, and emptying the water tank
frequently is recommended to prevent odors or mildew.
· Remove the mop cloth bracket if not mopping.
��. Separating the water tank from the mop cloth bracket
As shown in the figure, press the two side clips inwards
and slide the mop cloth bracket backwards to separate it
from the water tank.
��
