Summary of Contents for Roborock S5 Series

  • Page 1 Roborock Robotic Vacuum Cleaner Manual Please read this manual carefully before using the product and keep it properly...

  • Page 3: Safety Information

    Safety Information IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING (THISAPPLIANCE), Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING To reduce the risk of fire, electric shock, or injury: Do not use outdoors or on wet surfaces...
  • Page 4 Safety Information For use only with roborock CDZ02RR or CDZ06RR charger.Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of ba ery pack may create a risk of fire when used with another ba ery pack.
  • Page 5 Safety Information Do not use the vacuum cleaner on a wet surface. Risk Of Injury. Brush May Start Unexpectedly.Disconnect the main Brush Before Cleaning or Servicing. Do not use the product when the temperature is higher than 40℃ or lower than 4℃, or there is any liquid or sticky substance on the floor SAVE THESE INSTRUCTIONS Household use only...
  • Page 6 à la position marche peut causer un accident. Pour emploi seulement avec roborock CDZ02RR or CDZ06RR chargeur.Recharger uniquement avec le chargeur prescrit par le fabricant. Un chargeur convenant à un type de ba erie peut présenter un risque d’incendie lorsqu’...
  • Page 7 Safety Information Ne pas utiliser une ba erie ou un appareil endommagé ou qui a été modifié. Des ba eries endommagées ou modifies peuvent avoir un comportement imprévisible pouvant causer un incendie, une explosion ou un risque de blessure. Ne pas exposer une ba erie ou un appareil à la flamme ou à des températures excessives. L’exposition à une flamme ou à...

  • Page 8: Fcc Statement

    Compliance Statement and (2) this device must accept any interference received, including interference that may cause undesired operation Correspondence of the responsible party in USA Company Roborock Technology Co. Address 108 West 13th Street, Wilmington, Delaware 19801. Email support@roborock.com Warning: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 9: Can Ices-3 (B)/Nmb-3(B)

    FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 10: Battery And Charging

    Battery and Charging Please keep the dock charger away from heat (such as heating plates) The battery must be removed from the appliance before it is scrapped The appliance must be disconnected from the supply mains when removing the battery The battery is to be disposed of safely.Please do not discard waste batteries.

  • Page 11: Product Introduction

    Product Introduction Main Unit Cleaning On/Off Short press to start cleaning Press and hold to turn on or off Wall sensor Circular indicator light White: power ≥20% Red: power ＜20% Slow blinking: charging or launching Red flash: fault status Bumper Cliff sensor Spot cleaning Short press to start regional cleaning...
  • Page 12 Product Introduction Dust Bin WIFI indicator light Dust bin lid Dust bin buckle Slow blinking: Waiting to connect Fast blinking: Connecting Stable light: Wi-Fi is connected Filter System Reset button Speaker Air vent Accessories Cleaning tool of main brush Water tank Mopping cloth Moistureproof mat Power cable...

  • Page 13: Installation

    Installation Plug the dock charger into the interface of the Turn on and charge the machine moistureproof mat, and make sure it's firmly Press and hold the button to turn on the main unit ,wait until the installed. indicator light is on for a while ,then place the main unit on the dock charger to charge.
  • Page 14 Installation The product is compatible with Mi Home intelligent platform and could be controlled by Mi Home app. It supports the MIUI system and can be interconnected with other Mi Home intelligent products Quick Setup Download App Search "Mi Home" in App store/Google play or scan the QR code below to download and install the Mi Home app. Add Device Go to "My Device"...
  • Page 15 Installation WIFI indicator light Note:Do not use the mopping module when no one is at home Slow blinking: Waiting to connect Fast blinking: Connecting Fill the water tank:Open the tank lid,fill it with water,and put back Stable light: WIFI is connected the tank lid.
  • Page 16 Installation Operating Instruction Start cleaning Main brush * Clean it every week as recommended When the circular indicator light on the main unit changes from 1. Turn over the machine, press the buckle and take off the cover. slow blinking to stable,it means charging has completed.Briefly 2.

  • Page 17: Daily Maintenance

    Daily Maintenance Change of filter Instruction for using the cleaning tool of the main brush Pour the water into the dust bin, close the dust bin cover, shake Please remove the filter and replace it as shown in the picture. the dust bin left and right, pour out the dirty water, repeat this step several times, until the filter clean.
  • Page 18 Daily Maintenance Main Unit Sensor Omni-directional wheel Wipe the sensors of the main unit with a soft, dry cloth, including: It is recommended to clean it every month 1. The four cliff sensors at the bottom of the main unit. 1.

  • Page 19: Basic Parameters

    Daily Maintenance Basic Parameters Holiday Energy Saving Function Main Unit When the cleaner is on the charging dock, hold and press Item Parameters "Recharge" for 10 seconds until you hear a "Ding-dong" Size 353 350 96.5mm sound, and Holiday mode will be activated. Battery Lithium-ion battery 14.4V/5200mAh In this mode, the LED indicator will dim, functions that has...
  • Page 20 Address : Floor 6, Suite 6016,6017, 6018, Building C, Kangjian Baosheng Plaza, No. 8 Heiquan Road, Haidian District, Beijing, P.R. CHINA For more product information, please visit our website: www.roborock.com For after-sales support, please email our after-sales service team: US/Non-Europe Support: support@roborock.com...
