Altronix AL1042ULADA Installation Manual page 6

For the above modes DIP Switch 4 determines which Input controls the corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by Input 1.
Switch 4 in the OFF position causes output(s) to be controlled by Input 2.
Note: It is required to control visual notification appliances (strobes) via
Input 1 (IN1) and audible notification appliances (horns) via Input 2 (IN2).
This allows audible notification appliances (horns) and visual notification
appliances (strobes) to be silenced/ deactivated at same time.
The FACP must be capable of a visual annunciation to the silencing status of
the output or zone(s) to which the AL1042/R1042ULADA (NAC Power Extender) is connected.
Function
Amseco
Sync Mode*
®
Gentex
Sync Mode*
Gentex is a registered
trademark of
Gentex Corporation.
®
System Sensor
Sync Mode*
System Sensor is a
registered trademark
of Honeywell.
®
CooperWheelock
Sync Mode*
CooperWheelock is a
registered trademark
of Cooper Wheelock.
*Note: AL1042ULADA, R1042ULADA will only synchronize horns, horn/strobes, and strobes that contain
synchronization capability. The same synchronization mode must be selected for all outputs.
Amount of Notification Appliances per NAC:
Amseco
®
Gentex
*Not to exceed a maximum of 2.5A per NAC.
- 6 -
Sync Mode Selection Table:
Switch Positions
Descriptions
ON OFF
This mode is designed to work with the Amseco series of horns, strobes,
and horn/strobes to provide a means of synchronizing the Temporal-
1, 3,
2 coded horns, synchronizing the flash timing of the strobe, allowing
4
audible notification appliances (horns) and visual notification appliances
(strobes) to be silenced/deactivated at the same time.
This mode is designed to work with the Gentex
and horn/strobes to provide a means of synchronizing the Temporal-
1, 2,
coded horns, synchronizing the flash timing of the strobe, allowing
3, 4
audible notification appliances (horns) and visual notification appliances
(strobes) to be silenced/deactivated at the same time.
This mode is designed to work with the System Sensor
strobes, and horn/strobes to provide a means of synchronizing the
1, 2, 4 3 Temporal-coded horns, synchronizing the one-second flash timing of the
strobe, allowing audible notification appliances (horns) and visual notifica-
tion appliances (strobes) to be silenced/deactivated at the same time.
This mode is designed to work with the CooperWheelock
horns, strobes, and horn/strobes to provide a means of synchronizing the
2, 3, 4 1 Temporal-coded horns, synchronizing the one-second flash timing of the
strobe, allowing audible notification appliances (horns) and visual notifica-
tion appliances (strobes) to be silenced/deactivated at the same time.
27 per NAC*
32 per NAC*
®
System Sensor
®
CooperWheelock
AL842LGK Board
Output DIP Switches
®
series of horns, strobes,
32 per NAC*
32 per NAC*
AL1042ULADA / R1042ULADA Installation Guide
INPUT SELECT
TEMPORAL
STROBE SYNC
IN>OUT SYNC
®
series of horns,
®
series of
