MAIN PARTS
4
MAIN PARTS
Prostyle
Generator box
4
Prostyle Intra X-ray Unit
Support arm
Control panel
One end of the control panel cable is connected to the
terminal at the under-side of the generator box, and the
other end to the control panel.
CAUTION Do not connect any other equipment to the control
panel's terminal.
Scale for cone angle
Tube head
User's manual
