5. LOCAL CONFIGURATION

The Home Basic Edition can be configured locally using
the rotary switches and dip switches on the chargepoint.
Make sure that the charge point is not yet powered on
before configuring the features described in this chapter.

5.1 POWER SETTING

Select the maximum allowed current for the installed
circuit. Take the MCB, RCD, grid connection and local
regulations into account. Use table 1.1 to determine your
desired position of the left rotary switch, as indicated in
the '2.4.2 Overview Installing Accessories' section.
Rotary Position Maximum
allowed current
0 16 A
1 20 A
2 25 A
3 32 A
4 16 A
5 20 A
6 25 A
7 32 A
Table 1.1: Maximum allowed current
INSTALLATIEHANDLEIDING – P25
INSTALLATION MANUAL – P25 | P25
5.2 DYNAMIC POWER MANAGEMENT
SETTING
Enable Dynamic Power Management if the CT is
installed. Use table 1.2 to determine your desired
position of the right rotary switch, as indicated in the
'2.4.2 Overview Installing Accessories' section. Select
the maximum allowed Dynamic Power Management
current for the installed circuit. Take the MCB, RCD,
grid connection and local regulations into account.
Rotary Position
0
1
2
3
4
5
6
7
8
9
A
B
C or greater
Table 1.2: Dynamic Power Management current
VERSION 0129NM02INT01
06ANM20INT01
Dynamic Power
Management current
Dynamic Power
Management disabled
16 A
20 A
25 A
32 A
35 A
40 A
50 A
63 A
70 A
80 A
90 A (7,4 kW model only)
100 A (7,4 kW model only)
