- Page 1 Quick User and Installation Guide Advanced Flex 1.1 Powered by Shell Recharge - driven by you. Quick User and Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 3 Quick User Guide Advanced Flex 1.1 Powered by Shell Recharge - driven by you. Quick User Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 4 Ce document est le guide d'utilisation rapide de la borne Este documento é o guia rápido do usuário do ponto de de recharge Advanced Flex 1.1. Utilisez le code QR ou carregamento Advanced Flex 1.1. Use o código QR ou URL l'URL pour ouvrir le manuel d'utilisation en ligne détaillé.
- Page 5 Available Blinking slow Charging Solid Full / idle Solid Updating / unavailable Blinking Error Shell Recharge app 1. Activate charge point 1. Download 2. Activate 3. Activate More info Shell Recharge App charge card charge point Quick User Guide – Advanced Flex 1.1 - AF11SRQUIG04...
-
Page 6: Start Charging
2. Start charging Pulsating Charging Quick User Guide – Advanced Flex 1.1 - AF11SRQUIG04... -
Page 7: Stop Charging
3. Stop charging Quick User Guide – Advanced Flex 1.1 - AF11SRQUIG04... - Page 9 Quick Installation Guide Advanced Flex 1.1 Visit shellrecharge.com/installer to find out more. Powered by Shell Recharge - driven by you. Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 10 Extended manual For more information see the extended manual online: shellrecharge.com/installer Quick installation guide 6 ACHTUNG! Stellen Sie immer sicher, dass die Stromversorgung abgeschaltet ist, bevor Sie das Disclaimer - This document is the Quick Installation Guide Produkt installieren oder warten. Eine Installation of the Advanced Flex 1.1 charge point.
- Page 11 Snabbinstallationsguide Przewodnik szybkiej instalacji Varning - Detta dokument är snabbinstallationsguide för Zrzeczenie się - Ten dokument to Instrukcja szybkiej laddaren Advanced Flex 1.1. Använd QR-koden eller instalacji punktu ładowania Advanced Flex 1.1. Użyj kodu länken för att se den fullständige installationsanvisningen. QR lub adresu URL, aby zobaczyć...
- Page 12 Charge point serial number <Taal><Versienummering> | 02/2023 Rigakade 20, 1013 BC | Amsterdam, The Netherlands +31880109500 | www.shellrecharge.com Charge point serial number <Taal><Versienummering> | 02/2023 Rigakade 20, 1013 BC | Amsterdam, The Netherlands +31880109500 | www.shellrecharge.com Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 13 Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 14 Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 15 Ø8 mm Ø8 mm 5 × 60 mm Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 16 ଖ ଖ 3 cm ~20 cm ~1 cm Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 17 10 Nm ~1 cm ~23 cm 10 Nm Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 18 ~ 40 cm 5 × 60 mm Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 19 ଖ ଖ M3 × 12 (2×) 1.1 Nm M4 × 12 (5×) 2.0 Nm Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 20 !CLICK! !CLICK! Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 21 ଖ ଖ 1 2 3 4 5 6 7 8 RJ45 Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 22 ଖ ଖ Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 23 ଖ ଖ L1 L2 L3 Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 24 + - + - + - 1 2 3 4 5 6 + - + - + - + - + - + - Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 25 Option 1: L1-L2-L3 Option 2: L3-L1-L2 Option 3: L2-L3-L1 Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 26 3 4 5 6 7 8 – – – Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 27 – – – 5 6 7 8 – – Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 28 – – 1 Leader ≤31 Followers Leader Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 29 M4 × 12 (6×) 2.0 Nm Charge point serial number <Taal><Versienummering> | 02/2023 Rigakade 20, 1013 BC | Amsterdam, The Netherlands +31880109500 | www.shellrecharge.com Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 30 Quick Installation Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 31 Quick User Guide – Advanced Flex 1.1 - AF11SRQUIG04...
- Page 32 RF technology band range (MHz) power (dBm) Vereinfachte Konformitätserklärung 1920-1980 1710-1785 Hiermit erklärt Shell E.V. Charging Solutions B.V., dass die in den 880-915 23.7 Ladestationen des typs Advanced Flex 1.1 verwendete 832-862 Funkanlage mit der Richtlinie 2014/53/EU konform ist. Der 703-748 vollständige Text der EUKonformitätserklärung ist unter folgender...
- Page 33 2412-2472 19.99 880-915 23.7 832-862 703-748 Dichiarazione di conformità semplificata GSM/GPRS 880-915 Con il presente, Shell E.V. Charging Solutions B.V. dichiara che GSM/GPRS 1800 1710-1785 l'apparecchiatura radio tipo Advanced Flex 1.1 è conforme RFID 13.56 MHz 13.56 -8.2 alla direttiva 2014/53/UE. Il testo completo della WLAN 2.4 GHz...
- Page 36 Charge point serial number AF11SRRL01 | 07/2024 Rigakade 20, 1013 BC | Amsterdam, The Netherlands +31880109500 | www.shellrecharge.com...
