2. FIRST INSTALLATION

2.1 First Installation
Please check your network environment, if there is a BOOTP/DHCP server in your LAN then begin from step 1, otherwise start
from step 9.
1. Connect the SNMP/WEB Interface device in your LAN.
2. Open the internet browser and link to the SNMP/WEB Interface device by typing the default host name "SNMP/WEB Interface"
in the address edit box.
3. Login as administrator with "admin" account and "password" for default password.
4. Open the "User Manager" page to manage your accounts and passwords.
5. There is a limitation in the "User Manager" page to restrict the login users to login in the same LAN or not. Select "Only in This
LAN" option to restrict this login account can only login in the same LAN with the SNMP card, selecting "Allow Any" allows this
account to login from anywhere.
6. Switch to the "System Configuration" page and change the default Host Name.
7. Configure the IP address, Subnet Mask, Gateway IP for SNMP/WEB Interface device. If there is no DNS server then you need to
assign IP address for mail server if you want to be notified e-mail.
8. We recommend you to disable the BOOTP/DHCP option and assign a valid static IP address.
9. Open the "Time Server" page to synchronize the SNMP/WEB Interface device and time server. Please refer to next section on
how to construct your SNTP server.
If you have no BOOTP/DHCP server in your LAN then follow belows:
10. Make sure both of the SNMP/WEB Interface device and your workstation are in the same LAN.
11. Open EzSetting from CD, and refer to next chapter for configuring SNMP/WEB Interface by EzSetting.
12. You need to change the Host Name, IP Address,...
13. Because there is no BOOTP/DHCP server in your network environment, you need to disable BOOTP/DHCP option in the System
Configuration group.
14. Please refer to next Chapter "Configuring the SNMP/WEB Interface by EzSetting" section for more detail information on confi-
guring the SNMP/WEB Interface in an easy way.

2.2 Trouble Shooting

1. How to provide a SNTP(Simple Network Timer Protocol) server for SNMP/WEB Interface?
Answer: Install the "Simple TCP/IP Services" of "Networking Services" from "Add/Remove Windows Components". You may
need a Windows CD while installing.
Don't forget to provide the IP address of the host in the Time Server page.
2. How to make sure the network connection is established between my workstation and SNMP/WEB Interface?
Answer: Check the networking connection by typing the following command "ping HostName or IP" from your workstation.
3. In the browser, I can see the "Login" page but cannot login?
Answer: Please check the IP addresses of the SNMP
card and the PC which you try to login. If both of
the IP addresses are not in the same LAN then
please run the EzSetting utility to configure the
User Limitation to Allow Any.
6 - Ref.: IOMNETRTXX02-GB 01
