1. INTRODUCTION

1.1 Model Differences

There are 2 models for SNMP card: One is SNMP/WEB Interface SNMP card with golden finger connector, the other one is mini
SNMP card. Their outlines are as the following:
• SNMP/WEB Interface SNMP Card
There is an additional COM port for
SNMP/WEB Interface SNMP card with
golden finger. This COM port is used
to do the configuration or connect to a
environmental sensor box.
• mini SNMP Card
Due to the limitation of PC board size,
mini SNMP card has no COM port;
other than that, the other features are
all the same.
The settings of Dip Switch are different, too. In the normal mode, SNMP/WEB Interface SNMP card needs to set the dip
switches to the OFF position but the mini SNMP card needs to set to the ON position.
