HDMI OVER IP EXTENDER
FAQ
Q: Yellow light of Lan port is flashing but slowly!
A: 1): Check whether HDMI Extender TX and HDMI Extender RX is reversed.
2): Check whether HDMI source device output HDMI signal correctly.
3): Change the HDMI cable of TX.
Q: Yellow light of Lan port is flashing quickly but no display?
A: 1): If HDMI source is graphics card, please set the resolution to be supported by display device.
2): Check whether HDMI cable of RX is well connected.
3): Change the HDMI cable of RX.
Q: Yellow Led light of Lan port is not light?
A: 1): Check connection of network cable.
2): Network cable is too long.
Q: Q: Abnormal color display or flashing after all the devices are well connected.
A: 1): Pls press reset button of HDMI extender.
2): Follow the standard of IEEE-568B.

TECHNICAL SPECIFICATIONS

Power Supply
Supports resolutions
Working Temperature
Link Connector (Sender/Receiver)
Power Consumption
Relative Humidity
Dimensions
Weight
The product is compliance with EMC Directive 2004/108/EC
2pc X DC 5V/1A
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz,
1080p@50/60Hz
-10°C~60°C
UTP/STP CAT5e/6
3W (max) each
20%~90%
110 x 58 x 26 mm
239 g
