IQ 700IS
Intrinsically Safe Weight Indicator
NOTE: IQ 700IS c ontrol drawings are not
included in this PDF version of the manual.
Installation Manual
36528

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQ 700IS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rice Lake IQ 700IS

Summary of Contents for Rice Lake IQ 700IS

  • Page 1 IQ 700IS Intrinsically Safe Weight Indicator NOTE: IQ 700IS c ontrol drawings are not included in this PDF version of the manual. Installation Manual 36528...

  • Page 2: Table Of Contents

    2.1 Hazardous Area Installation of the IQ 700IS ....... . .
  • Page 3 6.3 Specifications ..............32 IQ 700IS Limited Warranty........................35...

  • Page 4: About This Manual

    Factory Mutual Approval unit is equipped with a tilt stand base for tabletop or wall mounting applications. The indicator front panel The IQ 700IS is Factory Mutual (FM) approved for: consists of a 21-button keypad, six seven-segment • Classes I, II, and III, display digits and 11 LED annunciators (see •...

  • Page 5: Front Panel Keypad And Annunciators

    +SEN to +EXC and –SEN to –EXC. Front Panel Keypad and Annunciators Figure 1-1 shows the IQ 700IS front panel. The IQ 700IS display consist of a six seven-segment display digits. Table 1-1 lists the front panel keys and their functions.
  • Page 6 Table 1-2 summarizes the front panel annunciator functions. Annunciator Function LOW BATTERY On when DC output voltage drops below normal operating range. ZERO On when scale weight is within ±0.25 displayed graduations of zero. Used in gross weighing mode only. On when the indicator is in net weighing mode.

  • Page 7: Installation And Wiring

    Installation and Wiring Drawings Required for this Installation This section describes the procedures for installing the IQ 700IS indicator, including load cell, digital input Table 2-1 shows the IQ 700IS control drawing and serial communications cabling. numbers and titles. The IQ 700IS drawings are included in the back of this manual.

  • Page 8: Ac Power Wiring

    Conduit is not required for Power Supply to Indicator: this installation. However, a separate conduit system Maximum Cable Length, is recommended. The type suggested for this application is 3/4 inch rigid steel conduit with pull Group Cable 1 Cables 2 & 3 boxes located at required intervals.

  • Page 9: Instrumentation Setup

    To ensure that the IQ 700IS is in proper operating condition, the indicator can be tested in a safe area Low Battery Annunciator with a load cell simulator. The input signal should be as close as possible to the normal system millivolt value.

  • Page 10: Load Cell Wiring

    +EXCITATION stripped and tinned wires for connection to a junction –EXCITATION box. The IQ 700IS is supplied with a blank six-pin +SIGNAL connector that can be attached to existing load cell –SIGNAL cables by the installer.

  • Page 11: Serial Port Wiring

    five-pin female connector (J3) located on the back communications. Port 1 is optically isolated through of the IQ 700IS indicator (see Figure 2-9). See the the intrinsically safe I/O barrier. output connector diagram in Figure 2-9 and Table 2-5 for connector and wire identification.

  • Page 12: Configuration

    Configuration Prior to calibration, the IQ 700IS must be digitally When configuration is complete, set SW1-2 open configured, or assigned a set of operating parameters. (down) to return the unit to normal operating mode. The first three parameters are directly related to...
  • Page 13 Resolution 1000 Legal for trade values: 500–10000 1500 (Refer to Paragraph 4.3) 2000 2500 3000 4000 5000 6000 8000 10000 12000 Not valid in legal-for-trade applications 14000 16000 18000 20000 Table 3-2. Configuration Display Prompt 1 IQ 700IS Installation Manual...
  • Page 14 Prompt Display Interpretation Notes 30000 Not valid in legal-for-trade applications These selections available only if Option 1 (Expanded Resolution) is enabled 40000 50000 60000 70000 80000 Table 3-2. Configuration Display Prompt 1 (Continued) Prompt Display Interpretation Notes Resolution / display divisions Scale capacity = displayed graduations x resolution Resolution is determined by the combination of Parameters 2 and 3.
  • Page 15 Prompt Display Interpretation Notes Setpoint mode Not supported; Ensure OFF Zero band control Not supported output Truck mode Not supported; Ensure NORM Serial configuration Section 3.2 on page 13 Table 3-6. Configuration Display Prompts 11 – 14 IQ 700IS Installation Manual...

  • Page 16: Serial Configuration

    Serial Configuration Serial Port 1 is an ASCII-compatible, 20 mA current loop output. Port 1 output can be disabled, set for demand mode, or set to continuous output data. Table 3-7 shows the configuration selections for Parameter 14, which controls the configuration of Port 1. There is no external access to Port 2 and it should therefore be disabled (Parameter 14.5 set to OFF).

  • Page 17: Options Configuration

    Options 1, 2, 3, 4, or 6 or ZERO key to scroll backward through the TARE RECALL The IQ 700IS offers a selection of optional features options. To enable a selected option, use the that are available in the configuration of the indicator. GROSS/NET key.
  • Page 18 The Option 2 configuration is shown in Table 3-9. Detailed information about the Option 2 analog output configuration is contained in RLWS manual P/N 63223. Prompt Option Display Interpretation Notes All off -------- Mode not enabled (Options 1 through 10 —...

  • Page 19: Option 3 - Time And Date

    Time and date can be directly accessed in normal running mode by pressing both the keys for a few seconds. This allows the time or date to be changed without using the Option switches. To exit, press key. IQ 700IS Installation Manual...

  • Page 20: Option 4 - Auto Shutoff Mode

    3.3.4 Option 4 – Auto Shutoff Mode The auto shutoff mode can prolong battery life for applications using the battery input power to the indicator. ZERO Option 4 allows the indicator to be configured to shut GROSS MOTION off automatically when idle for a specified time (1–9 CAPACITY CLASS III/III L minutes).

  • Page 21: Option 7 - Smart Serial I/O

    (gross, net, total recall, reserved for future use). Each of the custom transmit or special) that the IQ 700IS is currently in at the time files may contain up to 30 character codes. If you need of a print.
  • Page 22 Macro Files At this point, it is recommended that you get your There may be times when you need to print more than indicator, printer (hook up per instructions), and the 30 character codes that are allowed in the custom manual and follow along, or read first and then go transmit files (7.1 - 7.4).
  • Page 23 Format 1: GROSS weight (line 4) Format 2: GROSS (ln 4), TARE (ln 5), NET (ln 6) Carriage return Line feed END OF FILE Table 3-15. Print File 7.2 Example (7.2, Co. Logo, T/D, GR, TR, NT) IQ 700IS Installation Manual...
  • Page 24 NOTES: GLEN CO inc. • When necessary, the start of text (STX) GLENWOOD MN. character tells the printer that data is being 10:22 PM 04/16/02 transferred for printing. 10000 LB GR • A macro does not repeat the start of text 5000 LB TR character.
  • Page 25 files to print custom transmits up to 250 characters long. • You may use any of the ASCII codes (see Table 6.2 on page 37) and parameter control codes (see Table 3-18 on page 23). IQ 700IS Installation Manual...
  • Page 26 1 SETPOINT respectively, from your custom transmit files. • To delete a code from the table, select the code • Parameter 700 causes the IQ 700IS to pause for using the 1 SETPOINT 2 SETPOINT keys, the delay period specified in parameter 14.2.

  • Page 27: Calibration

    Calibration The IQ 700IS indicator can be calibrated using single slope span calibration or five-point linearization. Zero must be calibrated (see Section 4.1) before either span or linearization calibration can be performed. NOTE: Unit requires 6 wire load cell cable or jumpers (see Figure 2-7 on page 7). If anything other than 6 wire is used, deadload will not adjust.

  • Page 28: Five-Point Linear Calibration

    Five-Point Linear Calibration There are five calibration points (La, Lb, Lc, Ld, and Le) that can be entered sequentially. Calibrations using fewer than five points will linearize the curve up to the last data point. The curve is then extrapolated from the last entry point.

  • Page 29: Normal Weighing Mode Operations

    This value Table 5-2. Function Key Description indicates to the operator the current EPROM that has been installed in the IQ 700IS. The IQ 700IS operates Gross/Tare/Net Weighing with an EPROM family group KDA 49.x (x is the Operations version).

  • Page 30: Tare Key Function

    5.4.3 TARE Key Function 5.4.5 Lb/Kg Conversion If the tare acquisition is greater than zero (+1/2 When Parameter 10 in the configuration mode is set to graduation), set the display to the net mode and apply Con (conversion), pressing the unit key toggles the the new tare.
  • Page 31 Table 5-3. Serial Data Character Descriptions Status Character Definitions The status character (<STAT>) provides information to the receiving device about the current indicator operation. Table 5-4 shows the status characters returned by the IQ 700IS indicator. Status Characters Description <D> (44H) Digital calibration mode <A>...

  • Page 32: Demand Mode Versus Continuous Data Output

    General Continuous Mode Output Data Format NOTES: Continuous mode is used to interface to computers, • Response data (xxxxxx) is six characters with scoreboards, and other remote devices requiring no decimal point, seven with decimal point. c o n s t a n t d a t a u p d a t i n g . C o n t i n u o u s m o d e Leading zeroes are shown as space characters.

  • Page 33: Appendix

    Appendix Error Messages The IQ 700IS indicator provides a number of error and status messages. When an error occurs, the message is shown on the indicator LCD display. Table 6-1 lists these messages and their meanings. Error Message Description Solution Err1 Loss of configuration...

  • Page 34: Ascii Character Chart

    ASCII Character Chart Control ASCII ASCII ASCII ASCII Ctrl-@ space Ctrl-A Ctrl-B “ Ctrl-C Ctrl-D Ctrl-E Ctrl-F & Ctrl-G ’ Ctrl-H Ctrl-I Ctrl-J Ctrl-K Ctrl-L Ctrl-M Ctrl-N Ctrl-O Ctrl-P Ctrl-Q Ctrl-R Ctrl-S Ctrl-T Ctrl-U Ctrl-V Ctrl-W Ctrl-X Ctrl-Y Ctrl-Z Ctrl-[ Ctrl-\ <...

  • Page 35: Specifications

    CoC Number 89-023A299-010 delay Accuracy Class III/III L Calibration Method Software, with optional : 10 000 five-point linearization Serial Communications Port 1 Full duplex 20 mA at 9600, 4800, 2400, 1200, 600, or 300 bps FM #0Z0AZ.AX IQ 700IS Installation Manual...
  • Page 36 OPTIONAL PANEL MOUNTING KIT 4.14 9.12 PANEL THICKNESS .03 THRU .75 ZERO GROSS MOTION CAPACITY 6.35 6.62 ON/OFF 3.94 FRONT VIEW SIDE VIEW 6.00 1.22 2X .50 MODEL NO. SER. NO. DATE INPUT VOLTAGE VAC 50/60 Hz ADD'L INFO SCALE ACCESSORY 790F LR47913 ®...
  • Page 37 CLASS II DIV. 1 GROUP E, F, G AND CLASS III WHEN USED WITH POWER SUPPLY 31221/31222, OR BATTERY ASSEMBLY 31215. INSTALL PER RLWS DWG 33476. 6.62 11.36 BATTERY MODULE 4.26 1.22 6.00 2X .50 2X .28 2.26 3.69 8X R TILT STAND Figure 6-2. Battery-Powered Unit Dimensions IQ 700IS Installation Manual...

  • Page 38: Iq 700Is Limited Warranty
