- Page 1 MEGA COLOUR 2000 PR-4200 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
- Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS STAND-ALONE MODE MASTER/SLAVE MODE LED INDICATION OPERATION MENU DMX PROTOCOL MAINTENANCE KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING TECHNICAL DATA...
-
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20. -
Page 4: Install The Projector
Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning. Always ensure that the structure that you are going to mount the projector is secure and is strong enough to support a weight of MEGA COLOUR 2000. WARNING: 1. -
Page 5: Power Supply-Mains
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. The body of the plug is not connected in any way. MEGA COLOUR 2000 accepts digital control signals in protocol DMX512 (1990). -
Page 6: Dmx Terminator
TO SET THE DMX START ADDRESS Each MEGA COLOUR 2000 must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller. -
Page 7: Standalone Mode
STAND-ALONE MODE To operate the projector without connecting a controller, setup options master mode disabled, the projector will run in Stand-Alone mode automatically. MASTER/SLAVE MODE Without using a controller, many projectors can run synchronously in the Master/Slave mode by linking them with each other. -
Page 8: Operation Menu
OPERATION MENU 5th LEVEL 6th LEVEL 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL PR LIGHTING MEGA COLOUR Address=001 2000 PR LIGHTING PR LIGHTING DMX Address DMX Address PR LIGHTING PR LIGHTING Reset Reset Are You Sure? PR LIGHTING DMX Mode... - Page 9 PR LIGHTING Disp Dim Level PR LIGHTING Disp Dim Level PR LIGHTING Disp Dim Level PR LIGHTING Disp Dim Level PR LIGHTING Disp Dim Level PR LIGHTING Disp Dim Level PR LIGHTING Disp Dim Level PR LIGHTING Disp Dim Level...
- Page 10 PR LIGHTING Turn Lamp On PR LIGHTING Turn Lamp Off Mode= DMX512 Select Memory User Memory 1 Select Memory User Memory 2 Select Memory Mode = Preset Memory 1 Master mode Select Memory Preset Memory 2 Select Memory PR LIGHTING...
- Page 11 Yellow Yellow XXX（0~255） Magenta Magenta XXX（0~255） Focus Focus Frost Frost Dimmer Dimmer Strobe Strobe Pan High Pan High Pan Low Pan Low Tilt High Tilt High Tilt Low Tilt Low M-Speed M-Speed XX(001~255） Delay Delay XX Seconds （0.25s~100min） Link To Step Link To Step XXX（1~32）...
-
Page 12: Dmx Protocol
DMX PROTOCOL SHORT STANDARD FUNCTION DESCRIPTION MODE MODE Linear adjust from light to dark CYM-Cyan 000-255 Linear adjust from light to dark CYM-Yellow 000-255 000-127 Linear adjust from light to dark C=Y=255 128-255 CYM colour mixing Macros from fast to slow CYM-Magenta C≠255 000-255 Linear adjust from light to dark... -
Page 13: Maintenance
MAINTENANCE If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end of its life and it should be changed at once, aged lamps run to the extremity of their life might explode. -
Page 14: Technical Data
TECHNICAL DATA VOLTAGES: 220V AC，50/60Hz Options: 230/240V AC，50/60Hz POWER CONSUMPTION: 2650W@220V LAMP: Type XQ2000 Colour Temperature 6000°K Socket Anode SFa27-14, Cathode SFc27-14, double ends Manufacturers Rated Lamp Life 800 hours COLOURS: Smooth CYM colour mixing system FOCUS: DMX controlled focus DIMMER: 0-100% linearly adjustable SHUTTER:... - Page 15 Fixture and lamp usage time display Overheating protection Adjustable brightness and contrast of LCD display HOUSING: High strength aluminium alloy and industrial plastic and composite plastic, IP20 WEIGHT: 58Kg SIZES: See at below LIGHT OUTPUT: 22° lux 7500 1870 15550 3880 1720 13°...
-
Page 16: Electrical Diagram
ELECTRICAL DIAGRAM 16/18... -
Page 17: Component Order Codes
COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 192010128 HCH120-24 POWER SUPPLY 040090044 IGNITOR POWER SUPPLY FOR LAMP 390120052 1000W RELAY 192010026 H380D100 THERMOSTAT 190010054 250V-10A 95℃ 290151221 HTD459-3M-6 TILT DRIVE BELT 290151243 HTD711-3M-10 PAN DRIVE BELT 030060022 230V/22W 120X120 FAN IN TOP BOX 030069010 3E-230B-W... - Page 18 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 321010260 Last Revision: 05: 02: 2007 18/18...
