PRO Scientific Bio-Gen PRO200 Operating Manual page 73

Stainless Steel with Blade:
Use the drawing below to assist with the sealed chambers listed.
Part Size Vol.
Number ml ml
15-09070 70 10-65
15-09600 600 40-500
36
PRO PRO Cover
200 250
(1)
X X 14-02700
X 14-02600
Upper
Bearing
(9)
03-10001
03-10001
Insert Plug Gasket
(2) (3)
N/A 14-02701 99-00022
14-00003 14-12601 99-00021
Tube and Rulon Blade
Collar Bearing Collar
(10) (11)
08-02115 03-12187 07-00003
08-02150 03-12187 07-00003
Rotor Rotor
Collar Shaft
(4) (5) (6)
07-00150 05-02115
07-00150 05-02150
Rotor Acorn Nut
Blade
(12) (13) (14)
04-02001 99-22049
04-02002 99-22049
"O" Ring
Washer
(7) (8)
99-05016 99-03302
99-05016 99-03302
S.S.
Chamber
(15)
11-00700
11-00600
