SMC Networks ITV0000 Series Manual page 2

15
Compact
With a simplified high-density circuit
board design, an extremely
compact size has been achieved.
Realizes space savings
and reduction of weight
for manifold use
Stations can easily be
increased or decreased
due to DIN rail mount
design.
Power supply
Pressure
Model
range
ITV001
0.1MPa
ITV003
0.5MPa
24VDC
ITV005
0.9MPa
12VDC
ITV009
–100kPa
• Equivalent to IP65
Linearity within ±1%
•
Hysteresis 0.5%
Repeatability ±0.5%
• High-speed response time 0.1sec
Features 1
mm
Output signal
Input signal
voltage
4 to 20mA
Analog output
0 to 20mA
1 to 5V
0 to 5VDC
0 to 10VDC
(full span)
(full span)
(full span)
(without load)
Lightweight
Full scale
Cable connectors
Straight type and right angle type are available.
Straight type
Built-in One-touch fitting
With error indication LED
Brackets
Flat and L brackets are available.
Option
• Cable connectors
Straight type
Right angle type
• Brackets
Flat bracket
L bracket
• High stability
Stable pressure control is possible even when a metal
cylinder is used.
ITV (Electro-pneumatic regulator)
IR
W
(Precision regulator)
100
g
Right angle type
Flat bracket L bracket
Mist separator
(0.01 µm or less) (0.3 µm or more)
Air filter
(5 µm or less)
