PCI Photon 8 Port RS232
5. Flow Control.
6. Advanced - see the section below, titled "Advanced Port
Settings."
7. Restore Defaults - when clicked, resets the selected COM port
to the following values:
Baud Rate:
Data Bits:
Parity:
Stop Bits:
Flow Control:

Advanced Port Settings.

When the Advanced button of Port Settings in selected the
following dialogue is displayed:
Settings available in this window are:
1. FIFO settings.
Use FIFO Buffers - turns the selected ports FIFO
buffer on or off. It is strongly recommended that the
FIFO for both ports is left enabled.
Receive Buffer - These settings allow the selection
of a receiver FIFO trigger setting. Selecting a low
value will lessen the likelihood of data loss due to
overrun errors when Photon 8 Port RS232 cards are
installed in slower host PCs running ports at higher
Software Installation
9600
8
None
1
Hardware
Chapter 3 Page 36
