PCI Photon 8 Port RS232
HARDWARE SPECIFICATIONS
Introduction.
This chapter details the specifications of the PCI Photon 8
Port RS232 serial card. These half-sized cards will work happily
in any PCI 2.0 (or greater) compliant PC compatible.
WARNING For Windows 98 Users Only.
Each PCI Photon 8 Port RS232 Card should be fully installed
before adding additional PCI Photon 8 Port RS232 cards.
PCI Photon 8 Port RS232 Card Features.
* Eight independent RS232 Serial ports.
* Reliable communications up to 50 feet, 15m, and beyond!
* 100% 16C550 PC Compatible serial port, up to 230,400 baud.
16550 Compatible FIFO provides 128 byte input and 128 byte
output buffer on each port.
* Full modem control TXD, RXD, DSR, DCD, DTR, RTS, CTS
and RI signals.
* Fully double buffered for reliable asynchronous operation.
High speed integrated circuitry ensures operation with fast PC's
e.g. 500 MHz Pentium II .
* Fully PCI 2.1 compliant.
* Fully Plug and Play
* Interrupt sharing system allows all ports to use a single interrupt
line while preventing any one port from hogging the processor.
CHAPTER 1
Specifications
Chapter 2 Page 6
