PCI Photon 8 Port RS232

Configuring Ports in Windows 95 and 98.

Although covering the installation of the PCI Photon 8 Port
RS232 cards into the Windows 95 operating system the procedure
is also valid, with only minor differences, in Windows 98. The
Windows 95 environment now supports up to 255 standard serial
ports.
Windows 98
The Windows 98 operating system procedure is the same as for
Windows 95 with only minor differences. The only significant
difference is that only one PCI Photon Card should be added to the
PC per restart. E.g. if three PCI Photon cards are to be installed
then the whole of the following procedure needs to be carried out
three times.

Windows 95/98 Installation Procedures

Insert the card in a free PCI slot, power up the PC.
Windows 95 should then load normally. During the booting
process, Windows 95 will detect the card and briefly display a
message box indicating the detection process.
Windows will then display the "Update Device Driver Wizard",
requesting " insert any disk which came with the PCI card" .
Insert the Serial Solutions CDROM installation disk into an
appropriate drive and click 'Next' and follow the path laid out
below.
Software Installation
Chapter 3 Page 25
