PCI Photon Twin 9
HARDWARE GUIDE
Introduction.
This chapter details the specifications of the PCI Photon
Twin 9 Serial card. These half-sized cards will work happily in any
PCI 2.0 (or greater) compliant PC compatible.
WARNING For Windows 98 Users Only.
Each PCI Photon Twin 9 Card should be fully installed before
adding additional PCI Photon cards.
PCI Photon Twin 9 Card Features.
* Two independent RS232 Serial ports.
* Reliable communications up to 50 feet, 15m, and beyond!
* 100% 16C550 PC Compatible serial port, up to 230,400 baud.
16550 Compatible FIFO provides 128 byte input and 128 byte
output buffer on each port.
* Full modem control TXD, RXD, DSR, DCD, DTR, RTS, CTS
and RI signals.
* Fully double buffered for reliable asynchronous operation.
High speed integrated circuitry ensures operation with fast PC's
e.g. 500 MHz Pentium II .
* Fully PCI 2.1 compliant.
* Fully Plug and Play.
* PCI enabled interrupt sharing.
CHAPTER 1
Hardware Guide
Chapter 1Page 6
