PCI Photon Twin 9

Table Of Contents.

C 1 HARDWARE GUIDE............................................. 6
HAPTER
Introduction. .......................................................................... 6
WARNING For Windows 98 Users Only. ............................. 6
PCI Photon Twin 9 Card Features......................................... 6
Configuring PCI Cards. ......................................................... 7
C 2 INSTALLING IN YOUR COMPUTER ................ 8
HAPTER
Serial Ca r d Installation. ......................................................... 8
r
Problems! ............................................................................ 10
C 3 SOFTWARE INSTALLATION ......................... 11
HAPTER
Introduction. ........................................................................ 11
Configuring Ports In Windows 3.x....................................... 11
Determining PCI Photon Twin 9 Resources. ........................ 11
Serial Solutions Installation for Windows 3.x ...................... 12
Serial Port Installation. ........................................................ 14
Adding an PCI Photon Twin 9 Serial Card........................... 15
Settings for Photon Twin 9 Card COM1 Present .................. 16
Settings for Photon Twin 9 Card COM1 & 2 Present ........... 16
Settings for Photon Twin 9 Card COM1 to 4 Present ........... 17
Configuring The COM Ports................................................ 18
Changing Serial Port Settings .............................................. 18
Deleting Ports in Windows. ................................................. 19
Restarting Windows............................................................. 19
Configuring Ports in Windows 95 and 98............................. 20
Windows 95/98 Installation Procedures ............................... 20
PCI Photon Twin 9 Card Settings In Win95/98. ................... 22
Force Configuration............................................................. 23
PCI Photon Twin 9 Card Port Settings In Win 95/98............ 24
Maximum Baud Rate Settings.............................................. 25
Configuring PCI Photon Twin 9 In Windows NT................. 28
Software Installation. ........................................................... 28
Examining Card Configuration. ........................................... 29
