SPECIFICATIONS*
Speed Settings:
Gravity Damper Rough Opening Dimensions:
Grille Construction:
Fan Diameter:
Duct Length:
Duct Diameter:
Electrical:
Fan Motor: (HP/FLA)
Damper Door Insulation:
Installation:
Attic Net Free Ventilation Area (Sq ft) **
Open Window Ventilation Area (Sq ft)**
*Due to our continual product improvement eff orts, performance ratings and specifi cations are subject to change without notice.
**Attic Net Free Ventilation and Open Window Ventilation Areas are listed as minimum requirements.
Actual lower ventilation areas may reduce fans overall performance at high speeds.
3 (OFF/LOW/HIGH) - 2 Speed Motors
14.25 inches W x 36.25 inches L
Aluminum Cube Core, Steel frame with White Powder Coat
2 - 18.75 inch sections
2 - 7 ft sections
2 x 16 inches
115VAC, 60 Hz
2 X 1/3 HP / 4.9 (each fan assembly)
R5 (compiled)
Installs easily on 24" or 16" O.C. framing
9.26
18.52
page 17 of 20
P/N 780104100 07/20 Rev B
