Form Factor
ETX
CPU Module
®
Video
Dual Channels 24-bit
LVDS, Analog RGB, DDI
port
LAN
Realtek RTL8105E
10/100 Base-T Ethernet
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
http://www.arbor.com.tw
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
All Rights Reserved.
®
EmETX-a55E0
CPU
Soldered onboard
AMD G-Fusion G-T56N
1.65GHz Processor
Audio
Realtek HD AUDIO
CODEC, Mic-in/ Line-in/
Line-out
Quick Installation Guide
- 1 -
ETX
CPU Module
®
Chipset
AMD FCH A55E
I/O
PCI/ ISA/ SATA/ USB
IDE/ COM/ LPT
4041550000110P
Version 1.1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology EmETX-a55E0
Summary of Contents for Arbor Technology EmETX-a55E0
- Page 1 EmETX-a55E0 CPU Module ® Quick Installation Guide Version 1.1 Form Factor Chipset Soldered onboard AMD FCH A55E CPU Module ® AMD G-Fusion G-T56N 1.65GHz Processor Video Audio Dual Channels 24-bit Realtek HD AUDIO PCI/ ISA/ SATA/ USB LVDS, Analog RGB, DDI...
-
Page 2: Packing List
Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EmETX-a55E0 ETX CPU Module ® 1 x Driver CD 1 x Quick Installation Guide Ordering Information EmETX-a55E0-T56N AMD G-Fusion G-T56N 1.65GHz ETX CPU Module ®... -
Page 3: Specifications
Specifications Form Factor CPU Module ® Soldered onboard AMD G-Fusion G-T56N 1.65GHz Processor Chipset AMD FCH A55E 1 x 204-pin DDR3 SO-DIMM Socket up to 4GB System Memory 1333MHz SDRAM Integrated Radeon HD 6320 with Analog RGB/ VGA/ LCD Controller 24-bit dual channels LVDS (Dual independent displays) Ethernet... - Page 4 Board Layout Top View Board Layout Bottom View - 4 -...
-
Page 5: Board Dimensions
Board Dimensions 47.63 27.94 45.59 Unit: mm - 5 -... -
Page 6: Pin Description
SATA1, SATA2 Connectors Description LPC1 Connector Connector type: FPC12-14P-P0.5 (Hirose) Description Description LAD0 BUF_PLT_RST# LAD1 LAD2 PCLK_CONN LAD3 LFRAME# +3.3V INT_SERIRQ +3.3V DDI1 Connector Connector type: FH12-26S-0.5SH (Hirose) Description Description DDI_TX0+ DDI_AUX+ DDI_TX0- DDI_AUX- DDI_TX1+ DDI_HPD DDI_TX1- SMB_DAT SMB_CLK DDI_TX2+ DDI_TX2- DDI_TX3+ +3.3V... -
Page 7: Etx1 Connector
ETX1 Connector ETX2 Connector A1 GND GND A2 B1 GND GND B2 A3 PCICLK3 PCICLK4 A4 B3 SD14 SD15 B4 A5 GND GND A6 B5 SD13 MASTER# B6 A7 PCICLK1 PCICLK2 A8 B7 SD12 DREQ7 B8 A9 REQ#3 GNT#3 A10 B9 SD11 DACK#7 B10 A11 GNT#2... -
Page 8: Etx3 Connector
ETX3 Connector ETX4 Connector C1 GND GND C2 D1 GND GND D2 C3 R B C4 D3 5V_SB PWGIN D4 C5 HSY G C6 D5 PS_ON SPEAKER D6 C7 VSY Analog RGB_DDC_CLK C8 D7 PWERBTN# BATT D8 C9 DETECT# Analog RGB_DDC_ATA C10 D9 KBINH LILED D10 C11 TX2CLK#...
