EmCOMe-i94U0
85
Form Factor
COM Express
Compact
®
Type 6 CPU Module
LAN
Intel
i226 Series PCIe
®
Ethernet Controller
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first on our
website.
http://www.arbor-technology.com
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
E-mail: info@arbor.com.tw
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
2024 All Rights Reserved.
©
COM Express
CPU
13
Gen. Intel
th
i7-1365UE/ i5-1335UE/
i3-1315UE/ U300E
Audio
HD Audio Link
Compact Type 6 CPU Module
®
Core™
®
- 1 -
Quick Installation Guide
Video
24-bit Dual Channels
LVDS/ DDI/ Analog RGB
I/O
USB / SATA/ PCIe / I
UART
Version 1.0
C/
2
85
Advertisement
Table of Contents
Related Manuals for Arbor Technology EmCOMe-i94U0
Summary of Contents for Arbor Technology EmCOMe-i94U0
- Page 1 EmCOMe-i94U0 COM Express Compact Type 6 CPU Module ® Quick Installation Guide Version 1.0 Form Factor Video COM Express Compact Gen. Intel Core™ 24-bit Dual Channels ® ® Type 6 CPU Module i7-1365UE/ i5-1335UE/ LVDS/ DDI/ Analog RGB i3-1315UE/ U300E...
-
Page 2: Packing List
Module Type 2, 3, 4, 5 and 6 support two connectors with four rows of pins (440 pins) Connector placement and most mounting holes have transparency between Form Factors. The differences among the Module Type 6 and EmCOMe-i94U0 are summarized in table below: Module Type... -
Page 3: Specifications
Specifications System ® Soldered onboard 13th Generation Intel Raptor Lake Core™ - i7-1365UE 3.7GHz (E-core) / 4.9GHz (P-core) - i5-1335UE 3.4GHz (E-core) / 4.6GHz (P-core) - i3-1315UE 3.3GHz (E-core) / 4.5GHz (P-core) - U300E 3.2GHz (E-core) / 4.3GHz (P-core) Memory 2 x DDR5 SO-DIMM 4800MHz up to 64GB BIOS AMI UEFI BIOS... -
Page 4: Ordering Information
Operating Humidity 10 ~ 95% @ 85 C (non-condensing) Dimensions (L x W) 95 x 95 mm (3.7” x 3.7”) Ordering Information ® EmCOMe-i94U0-WT-1365URE 13 Gen. Intel Core™ i7-1365URE WT COMe Compact Type 6 CPU Module, -40 ~ 85 ® EmCOMe-i94U0-WT-1365UE Gen. -
Page 5: Driver Installation
Driver Installation To install the drivers, please visit our website at www.arbor-technology.com and download the driver pack from the product page. - 5 -... -
Page 6: Board Dimensions
Board Dimensions Φ 2.7 * 6.0 Φ 46.23 Unit: mm - 6 -... -
Page 7: Connectors Quick Reference
Connectors Quick Reference Top Side SO-DIMM Socket Connector Bottom Side COM Express Connectors SO-DIMM Socket - 7 -... - Page 8 FAN: Fan connector Connector type: Wafer 3-pin 1.25mm 85204-0300L Description Fan out Fan Tachometer Input - 8 -...
- Page 9 COM Express AB Connector (bottom side) PCIE3_P3_RXN PCIE3_P3_TXN LAN1_MDI3N LAN_LED_LNK#_ACT DIO_6 LPC_FRAME# LAN1_MDI3P PCIE3_P8_RXP PCIE3_P8_TXP LPC_AD0 LAN_LED_1000# PCIE3_P8_RXN PCIE3_P8_TXN LPC_AD1 LAN_LED_2500# LPC_AD2 LAN1_MDI2N PCIE3_P7_TXP PCIE3_P7_RXP LPC_AD3 LAN1_MDI2P PCIE3_P7_RXN PCIE3_P7_TXN LPC_DRQ0# LAN_LED_LNK# DIO_1 DIO_7 LPC_DRQ1# LAN1_MDI1N PCIE3_P6_RXP PCIE3_P6_TXP LAN1_MDI1P LPC_CLK PCIE3_P6_RXN PCIE3_P6_TXN PCH_WAKE# LAN1_MDI0N...
- Page 10 COM Express CD Connector (bottom side) USB3_DWN_TXN1 USB3_DWN_RXN1 USB3_DWN_TXP1 USB3_DWN_RXP1 USB3_DWN_TXN2 USB3_DWN_RXN2 USB3_DWN_TXP2 USB3_DWN_RXP2 USB3_DWN_TXN3 USB3_DWN_RXN3 USB3_DWN_RXP3 USB3_DWN_TXP3 USB3_DWN_RXN4 USB3_DWN_TXN4 USB3_DWN_TXP4 USB3_DWN_RXP4 DDI0_CLK_AUXP DDI0_DATA_AUXN PCIE3_P2_RXP PCIE3_P2_TXP PCIE3_P2_RXN PCIE3_P2_TXN PCIE3_P10_RXP PCIE3_P10_TXP PCIE3_P10_RXN PCIE3_P10_TXN PCIE4_A_P0_EXP_TX_DP PCIE4_A_P0_EXP_RX_DP DDP0_HPD PCIE4_A_P0_EXP_RX_DN PCIE4_A_P0_EXP_TX_DN DDI0_PAIR_0P PCIE4_A_P1_EXP_RX_DP PCIE4_A_P1_EXP_TX_DP DDI0_PAIR_0N PCIE4_A_P1_EXP_TX_DN PCIE4_A_P1_EXP_RX_DN...
-
Page 11: Block Diagram
Block Diagram DDR5 5200MT/s 2 x SO-DIMM DDR5 sockets (HSIO 0) 4 x USB 3.0 ports USB Hub (CPU) 2 x PCIex4 2 x PCIex1 (HSIO 1,9) DDI0 TCP0 TCP1 DDI1 TCP2 DDI2 Intel Raptor Lake-U ® TCP3 Analog RGB DDI to VGA series Core i7/i5/i3...
