- Page 1 619/1834 131/8564 Width - 120.2cm Depth - 50.2cm Height - 75cm If you need help or have damage or missing parts, call the Argos Customer Helpline: 08456 400 800 or Homebase Customer Helpline: 0845 077 8888 Issue 1 - 12/09/12...
- Page 3 3 Division panel 1 Top panel (72.5 x 49.5cm) (120.2 x 50.2cm) 10 Small Drawer Left Side x 2 (32 x 12.6cm) 2 Left Side 4 Right Side (72.5 x 49.5cm) (72.5 x 49.5cm) 11 Small Drawer Right Side x 2 (32 x 12.6cm) 14 Large Drawer Front 13 Drawer bottom x 3...
- Page 4 If you have damaged or missing components, call the Argos Customer Helpline: 08456 400 800 or Homebase Customer Helpline: 0845 077 8888 Ø8x25mm Wooden dowel x 51 35mm Screw x 09 30mm Screw x 40 Handle x 03 14mm Screw x 09 Nails x 20 Ø6x25mm Wooden dowel x 16...
- Page 5 Fitting wooden dowels: Insert dowels into the indicated parts. Insert dowels on to the parts only. Attention...
- Page 6 Assembling cabinet: Carefully lay down top panel in a clean and soft surface. Fix small rail to the right side using screws Step 3 Assembling cabinet: Fix division panel the small rails using screws...
- Page 7 Step 4 Assembling cabinet: Fix the top front rail 5 and back rail 18 to the division panel 3 and left side 2 using screws A as shown. Step 5 Assembling cabinet: Carefully stand the product uprigth. Fix the top panel using screws Note correct position of...
- Page 8 Step 6 Fixing drawer runners: Fix drawer runners the side using screws as shown. Make sure holes on runners are facing up before fixing. Holes to face up. Step 7 Fixing drawer runners: Fix drawer runners the division using screws as shown.
- Page 9 Step 8 Insert wooden dowels: Carefully insert wooden dowels fully into the holes on the drawer runners as shown in the diagram. Only in the front holes. Step 9 Fixing back panel: Important: Cabinet MUST be “square” when back is attached.
- Page 10 This is a safety catch to stop drawers falling out. If you need help or have damage or missing parts, call the Argos Customer Helpline: 08456 400 800 or Homebase Customer Helpline: 0845 077 8888...
