- Page 1 Brixham Leather Eff Managers Chair 617/9131 Assembly Instructions - Please keep for future reference 617/3618 Width-60cm Depth-62cm Height-92 - 104cm 06/03/14...
-
Page 2: Safety During Use
Safety during use Do not stand on chair. Do not Use this product only for seating Do not use this chair unless all use this chair as a step ladder. one person at a time bolts, screws and knobs are firmly secured. -
Page 3: Components - Parts
Components - Parts parts Backrest Armrest x2 Seat (470x570x65mm) (430x250x60mm) (480x485x65mm) Mechanism Telescoping cover Gas lift (248x173mm) (Ф75x320mm) (Ф50x210mm) Brake castor x2 Star base Normal castor x3 (Ф50mm) (R300mm) (Ф50mm) - Page 4 Components - Fittings M6x20mm bolt x8 Ф15x9mm cap x8 M6x16mm bolt x4 5mm Allen key x1...
- Page 5 Attaching castors :Insert castors into star base Making sure they are in alternate positions on the base. :Turn star base over and place it on the floor. Insert gas lift into the center hole of star base :Place telescoping cover over the gas lift...
- Page 6 Attaching armrests Attach two armrests seat with bolts using allen key Step 3 Assembling the backrest Assemble armrests backrest with bolts...
- Page 7 Use cap to cover the hole of arms Attaching mechanism Attach mechanism seat with bolts...
- Page 8 Place the seat unit onto the top of the gas lift Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800...
- Page 9 Components Hi Back Leather Mix Manager's Chair 1 x Backrest C 1 x Left Armrest Simple Assembly Instructions Please keep for future reference B 1 x Seat Cushion F 1 x Right Armrest E 1 x Base D 1 x Seat Support I 8 x Plastic Plug J 5 x Castor G 1 x Gas Lift...
- Page 10 Assembly Instructions Assembly Instructions Stage 1 – Stage 3 – The Base Finishing the Unit 1. Use the Screw to fix the 1. Place all the five Castors J in the Backrest A in the Armrest. Then holes located under Base E . See fig.
