- Page 1 TC Belvoir Bamboo & White Shelving Unit 618/2915 80cm 30cm 136cm Issue 1 - 10/08/16...
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:03456 400800 Please check you have all the panels listed below Right leg x 2 Left leg x 2 Rail x 8 1st shelf 2nd shelf 3rd shelf 4th shelf...
-
Page 4: Tools Required
Components - Fittings Please check you have all the fittings listed below Note:The quantities below are the correct amount to complete the assembly .In some cases more fittings may be supplied than are required. Wooden dowel x 26 Locking Nut x 16 Locking Pin x 16 45mm Screw x 20 35mm Screw x 2... - Page 5 Assembly Instructions Step 1 Assembling leg NOTE:It would be useful to ask someone to help you at this stage. Using wooden dowel and 45mm screw to attach left leg right leg Screw locking pins into left leg and right leg...
- Page 6 Assembly Instructions Step 2 Assembling rails NOTE:It would be useful to ask someone to help you at this stage. Use 12mm screws to fix hanger bracket to the 2nd shelf as shown. Insert wooden dowel into left leg and right leg Attach rails onto the unit.
- Page 7 Assembly Instructions Step 3 Assembling shelf NOTE:It would be useful to ask someone to help you at this stage. Insert wooden dowel into rails Use cam caps to cover the locking nuts as shown. Attach 1st shelf onto the unit and use 45mm screw to fix it to the uint.
- Page 8 NOTE: Please make sure the unit is secure before use. The assembly is now complete. NOTE:If you have damaged or missing components, call the Customer Helpline:03456 400800 Argos LTD,489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
-
Page 9: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
