Verona Corner TV Unit

Assembly Instructions -

Dimensions

Width - 60cm

Depth - 40cm

Height - 59.5cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

609/5057

610/3475

issue 1 4/28/10

Need help?

Do you have a question about the Verona 609/5057 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Verona 609/5057

Page 1 Verona Corner TV Unit Assembly Instructions - 609/5057 Please keep for future reference 610/3475 Dimensions Width - 60cm Depth - 40cm Height - 59.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 issue 1 4/28/10...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Do not stand on the panels, this We do not components and tools listed on could cause damage. recommend the use pages 2 and 3.
Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below Back panel (57.5 x 20cm) Table top (60 x 40cm) Leg x 6 (19.3 x Ø3.5cm) Foot x 2 (4.7 x 3.4cm) Ø...
Page 4 Assembly Instructions Step 1 Step 1 Fitting the back panel Unscrew Cap screws a from the Feet Insert Legs into the first Shelf , then screw Feet into the Legs. Use Screws to fix the Back panel onto the Shelf...
Page 5 Assembly Instructions Step 2 Fitting the shelves Carefully locate the second Shelf onto the unit. Use Screws to fix the second Shelf onto the Back panel Screw in Legs to fix the second Shelf onto the unit. Continued on next page.
Page 6 Assembly Instructions Step 2 - continued Fitting the shelf Carefully locate the third Shelf onto the unit. Use Screws to fix the third Shelf onto the Back panel Screw in Legs to fix the third Shelf onto the unit.
Page 7 Assembly Instructions Step 3 Fitting the table top Screw Locking pins into the Top panel Carefully locate the Table top onto the unit. Continued on next page.
Page 8 Assembly Instructions Step 3 - continued Screw Cap screws to fix the Table top onto the unit. Use Locking nuts to fix the Table top onto the unit.
Page 9 Assembly Instructions Step 4 Finishing the unit Finally place the unit in the desired location. Note: Before use always make sure the unit is secure. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline : 08456 400800...
