ouble wardrobe
ssembly Instructions -
Dimensions
Width - 80.2cm
Depth - 54.5cm
Height - 189.7cm
Important -
Please read these instructions fully before starting assembly
For enquiries relating to spare parts please contact : 08456 400800
Please keep for future reference
615967012
615967022
615973512
615973522
Ref. no NEM 01.00 ate: 10/10/11
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 615967012
Summary of Contents for Argos 615967012
- Page 1 Instructions - 615967012 Please keep for future reference 615967022 615973512 615973522 Dimensions Width - 80.2cm Depth - 54.5cm Height - 189.7cm Important - Please read these instructions fully before starting assembly For enquiries relating to spare parts please contact : 08456 400800...
- Page 2 Safety and care advice Important - Please read these intructions fully before starting assembly • Assemble the unit as close • Check you have all the • We do not components and tools listed on to its final position (in the same recommend the room) as possible.
- Page 3 Components - Panels Please check you have all the panels listed below Shelf (76.9 x 51.6cm) (80.2 x 54.5cm) Double back panel Left side Right side (79 x 181cm) Left drawer (52 x 187.9cm) (52 x 187.9cm) side (40 x 16cm) Right drawer Drawer bottom side...
- Page 4 For enquiries relating to spare parts please Components - Fittings contact : 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 30mm Long locking Short locking...
- Page 5 Assembly Instructions Step 1 Preparation of side panels Fit wooden dowels Attach hinge plates Front side Fit metal dowels Fit long locking nuts Fix runner parts to the side panel through holes shown in the detail view using euroscrews and screws Bottom side Front side Bottom side...
- Page 6 Assembly Instructions Step 3 Preparation of shelf Attach wedgefix housing fitting to shelf Step 4 Preparation of bottom Fix wooden dowel c . Fit long locking nuts...
- Page 7 Assembly Instructions Step 5 Attaching panels Position side panels 1 and 2 onto bottom 5 and plinth Use a screwdriver to turn locking nuts b clock- wise to lock. Step 6 Fix of top panel Position top panel 4 onto the side panels 1 2 .
- Page 8 Assembly Instructions Step 7 Position back panel Fix the block support as shown, with screw Step 8 Attach back panels Important: Cabinet MUST be “square” when the back is attached Attach back panel 3 using 30 nails Fit support foot...
- Page 9 Assembly Instructions Step 9 Wall fixing Important: two people are needed here. To prevent possible overbalancing we recommend that this unit is secured to a suitable wall by use of the 'L' Bracket I fitted to the Not included Top of the unit. Fix the Bracket I loosely onto the top of the unit using spacer I screw R...
- Page 10 Assembly Instructions Step 10 Fittings have been supplied in order to join units together. If your unit has drawers you may need to remove them to reach some of the holes. Place units together in their final positon. Decide position where to drill through using a Ø5 mm bit.
- Page 11 Assembly Instructions Step 14 Step 11 Attaching shelf and hanging rail Fix Wedgefix dowels G onto the side panels 1 Block the shelf on the Wedgefix dowels G as shown. Fix hanger rail supports onto the side panels 1 using the screws Fit the hanging rail on the supports L as shown.
- Page 12 Assembly Instructions Step 12 Assembling of drawer Fit the RH 14 and LH 13 drawer sides to the drawer back 15 using 30 mm screws S Assembling drawer fronts Slide drawer bottom panel 11 into the drawer box grooves. Fit short locking nuts E to the drawer side panels 14 13 .
- Page 13 Assembly Instructions Step 14 Insert drawers Tilt the drawer as shown. Slide the drawer box along the runner parts until the stop. Wheels and runner parts have to be correctly matched as shown. Step 15 Fitting hinges to door Fix 3 hinges to each door 11 using 15 mm screws R .
- Page 14 Assembly Instructions Step 16 Hang door and fit handles Important: The Hinge Arm must be flat against the Hinge Plate. Slot door hinges onto the hinge plates tighten screw to lock hinges in position. Fit Handles using 35mm screw See step 17 (Hinge adjustment) if the doors need adjust- ment...
- Page 15 Assembly Instructions Step 17 Hinge adjustment Important: Before adjusting the Doors, use a spirit level to check the Base (or Top) of the unit is levelled front-to-back and side-to side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit levelled BEFORE making any adjustment to the hinges as shown.
-
Page 16: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
